HPE Aruba AP-567 (RW)

Name: HPE Aruba AP-567 (RW)
Brand: HPE
SKU: MME2M225DV
Price: 1416.80 EUR
Availability: InStock

View all HPE Access Points - Visit the HPE Store (R4W48A) - (MME2M225DV)

Model: HPE Aruba

Aruba AP-567 (RW) - radio access point - ZigBee, Bluetooth, Wi-Fi 6

Entry-level Outdoor Wi-Fi 6
IoT Ready
Simple Access With Enhanced Security

FREE Delivery on orders over €250

4 Available to Ship
Order within 8Hrs 7Mins for: FREE Delivery (8 Jun or 9 Jun)

RRP ~~€1955.90~~

€1416.80 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The HPE Aruba Networking 560 Series Outdoor Access Points provide cost-effective Wi-Fi 6 wireless connectivity in outdoor and environmentally challenging locations. With Wi-Fi 6 capabilities, Bluetooth 5 and 802.15.4/Zigbee radios, and maximum aggregate data rate of 1.49 Gbps, the 560 series delivers the speed and reliability needed to bring medium-density Wi-Fi 6 outdoors. These Wi-Fi 6 outdoor APs are ready to survive high wind, extreme temperatures, and moisture and can be quickly deployed using Zero Touch Provisioning. HPE Aruba Networking Central provides a single pane of glass for overseeing wired and wireless LANs, WANs, and VPNs. AI‑powered analytics, end‑to‑end orchestration and automation, and advanced security features are built natively into the solution. The 560 series outdoor APs include a limited lifetime warranty.

Features Summary

Entry-level Outdoor Wi-Fi 6
HPE Aruba Networking 560 Series Outdoor Access Points are ideal for environmentally challenging locations and can endure extreme temperatures, persistent moisture, precipitation, airborne contaminants, dust, salt sprays, and maximum 165 mph wind speeds.
Weatherproof and temperature hardened, this series can handle temperatures ranging from -40˚C to +65˚C, including full solar loading.
With maximum aggregate data rate of 1.49 Gbps (HE80/HE20), the series delivers the speed and reliability needed for most environments.
It supports features such as orthogonal frequency-division multiple access (OFDMA), downlink MIMO (MU-MIMO), and target wait time (TWT).
Enhanced wireless experience with HPE Aruba Networking ClientMatch technology removes sticky client issues by steering a client to the AP where it receives one of the best radio signals.
IoT Ready
HPE Aruba Networking 560 Series Outdoor Access Points can serve as IoT platforms that bolster network security and provide coverage for a range of IoT devices without the need for network overlays.
The AP supports Bluetooth 5 and Zigbee wireless protocols through an integrated IoT radio.
The target wake time (TWT) improves battery life of IoT devices.
HPE Aruba Networking Central Client Insights uses deep packet inspection to provide additional context and behavioral information that help verify devices are receiving proper policy enforcement and continuously monitor for rogue devices.
Simple Access With Enhanced Security
The HPE Aruba Networking 560 Series Outdoor Access Points offer enhanced security with Dynamic Segmentation to remove the time-consuming and error-prone task of managing complex and static VLANs, ACLs, and subnets by dynamically assigning policies and keeping traffic protected and separated.
It offers stronger encryption and authentication with WPA3, protected credentials/keys storage for guest access with Enhanced Open, and user and IoT access policy enforcement firewalls..
The AP simplifies policy enforcement by using the policy enforcement firewall to encapsulate all traffic from the AP to the gateway (or mobility controller) for end-to-end encryption and inspection.
For enhanced device assurance, the access points include an installed Trusted Platform Module (TPM) for protected storage of credentials and keys, and boot code.

Specification Summary

Product Description

HPE Aruba AP-567 (RW) - radio access point - ZigBee, Bluetooth, Wi-Fi 6

Device Type

Radio access point

Form Factor

External - outdoor

Data Link Protocol

IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, ZigBee, IEEE 802.11ac Wave 2, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)

Frequency Band

2.4 GHz, 5 GHz

Performance

Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (2.4 GHz): 574 Mbps

Capacity

Wireless clients per Wi-Fi radio: 256 ¦ BSSIDs per radio: 16 ¦ OFDMA units: 16

OS Required

ArubaOS, InstantOS 8.8.0.0

Power Over Ethernet (PoE) Supported

PoE+

Pricing Type

BTO

Dimensions (WxDxH)

16.5 cm x 16.5 cm x 11 cm

Weight

1.09 kg

Manufacturer Warranty

Limited lifetime warranty

Specifications

EAN / GTIN:

0190017447391

General

Device Type

Radio access point

Ruggedized Design

Outdoor

Width

16.5 cm

Depth

16.5 cm

Height

11 cm

Weight

1.09 kg

Networking

Form Factor

External

Connectivity Technology

Wireless

Data Transfer Rate

1.49 Gbps

Line Coding Format

CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM, 1024 QAM, OFDMA

Data Link Protocol

IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, ZigBee, IEEE 802.11ac Wave 2, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)

Spread Spectrum Method

OFDM, DSSS, OFDMA

Frequency Band

2.4 GHz, 5 GHz

Performance

Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (2.4 GHz): 574 Mbps

Capacity

Wireless clients per Wi-Fi radio: 256 ¦ BSSIDs per radio: 16 ¦ OFDMA units: 16

Status Indicators

System, status, radio

Features

Auto-uplink (auto MDI/MDI-X), Trusted Platform Module (TPM), reset button, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Virtual Mobility Controller mode, Advanced Cellular Coexistence (ACC), ClientMatch, cyclic shift diversity (CSD), MU-MIMO technology, packet aggregation A-MPDU, packet aggregation A-MSDU, Intelligent Power Monitoring (IPM), Dynamic Frequency Selection (DFS), High-Throughput (HT) support, Zero-touch provisioning (ZTP), Energy-Efficient Ethernet (EEE), waterproof, 2x2 MIMO technology, Very High Throughput (VHT) support, High Efficiency (HE) support, Target Wait Time (TWT), hardened, Wi-Fi 6 technology, Policy Enforcement Firewall (PEF), Layer 7 Deep Packet Inspection (DPI), Passpoint Release 2

Encryption Algorithm

WPA3-Enhanced Open, WPA2-MPSK

Aerial

Antenna

Internal

Directivity

Directional

Internet of Things (IoT)

Internet of Things (IoT) Compatible

Yes

Communications Technology

Bluetooth Low Energy (LE), Zigbee

Expansion / Connectivity

Interfaces

1 x 1000Base-T - RJ-45 ¦ 2 x aerial ¦ 1 x console - USB-C

Miscellaneous

Compliant Standards

CB, UL 2043, FCC, EN 60601-1-2, cTUVus, IP67, IP66, EN 60601-1-1, EMC 2014/30/EU, LVD 2014/35/EU, ISED, IEC/EN/UL 60950, ETSI 300 019-2-4, RED 2014/53/EU

Pricing Type

BTO

Power

Power Over Ethernet (PoE) Supported

PoE+

Power Consumption Operational

15.6 watt

Software / System Requirements

OS Required

ArubaOS, InstantOS 8.8.0.0

Manufacturer Warranty

Service & Support

Limited warranty - lifetime

Environmental Parameters

Min Operating Temperature

-40 °C

Max Operating Temperature

55 °C

Humidity Range Operating

5 - 95% (non-condensing)
