HPE Aruba AP-503H (RW) TAA Unified Hospitality - r

Images Manuals

HPE Aruba AP-503H (RW) TAA Unified Hospitality

Images for illustrative purposes

HPE Aruba AP-503H (RW) TAA Unified Hospitality

Name: HPE Aruba AP-503H (RW) TAA Unified Hospitality
Brand: HPE
SKU: ECE6159857
Price: 703.63 EUR
Availability: InStock

View all HPE Access Points - Visit the HPE Store (R3V37A) - (ECE6159857)

Model: HPE Aruba

Aruba AP-503H (RW) TAA Unified Hospitality - Radio access point - Wi-Fi 6 - 2.4 GHz, 5 GHz - BTO - TAA Compliant

Wi-Fi 6 Performance for Hotels, Dorms, and Remote Offices
Flexible Deployment and Unified Management
Ready for IoT
Simple and Secure Access

FREE Delivery on orders over €250

SPO - THIS ITEM CANNOT BE RETURNED AS UNWANTED AS IT IS A SPECIAL ORDER DIGITAL DOWNLOAD PRODUCT. **

Electronic Delivery By Email
Order within 7Hrs 52Mins for: FREE Delivery (8 Jun or 9 Jun)

€703.63 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

HPE Aruba Networking 500H Series Unified Hospitality Access Points delivers cost-effective Wi-Fi 6 coverage in a compact form factor that is ideal for hotels, residence halls, and remote offices. With 1.5 Gbps maximum combined speed, Zero Touch Provisioning, and wired ports, the 500H series is ready to improve wireless experiences for guests, employees, students, and teleworkers. The 500H series is Wi-Fi CERTIFIED and supports 802.11ax features: OFDMA for multi-user efficiency, target wake time (TWT) to extend the battery life of connected IoT devices, and WPA3 and Enhanced Open for greater password and guest security. The 500H series includes a limited lifetime warranty.

Specification Summary

Product Description

HPE Aruba AP-503H (RW) TAA Unified Hospitality - radio access point - Wi-Fi 6 - TAA Compliant

Device Type

Radio access point

Form Factor

External - indoor

Data Link Protocol

IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax

Frequency Band

2.4 GHz, 5 GHz

Performance

Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (2.4 GHz): 287 Mbps ¦ VPN throughput (IPSec): 100 Mbps

Capacity

Wireless clients per Wi-Fi radio: 256 ¦ BSSIDs per radio: 16

Power Over Ethernet (PoE) Supported

PoE Class 3

Pricing Type

BTO

TAA Compliant

Yes

Dimensions (WxDxH)

8.6 cm x 4.7 cm x 15 cm

Weight

360 g

Manufacturer Warranty

Limited lifetime warranty

Specifications

EAN / GTIN:

190017395616

General

Device Type

Radio access point

Ruggedized Design

Indoor

Width

8.6 cm

Depth

4.7 cm

Height

15 cm

Weight

360 g

Networking

Form Factor

External

Connectivity Technology

Wireless

Data Transfer Rate

1.5 Gbps

Line Coding Format

CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, 1024 QAM

Data Link Protocol

IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax

Spread Spectrum Method

OFDM, DSSS, OFDMA

Frequency Band

2.4 GHz, 5 GHz

Performance

Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (2.4 GHz): 287 Mbps ¦ VPN throughput (IPSec): 100 Mbps

Capacity

Wireless clients per Wi-Fi radio: 256 ¦ BSSIDs per radio: 16

Status Indicators

Port status, power, system, status, PoE

Features

Auto-uplink (auto MDI/MDI-X), DFS support, Wi-Fi Multimedia (WMM) support, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Advanced Cellular Coexistence (ACC), cyclic shift diversity (CSD), packet aggregation A-MPDU, packet aggregation A-MSDU, High-Throughput (HT) support, 2x2 MIMO technology, Very High Throughput (VHT) support, High Efficiency (HE) support, Target Wait Time (TWT), HPE SmartRate, Advanced IoT Coexistence (AIC)

Encryption Algorithm

WPA, WPA2, WPA3-Enterprise, Opportunistic Wireless Encryption (OWE), Simultaneous Authentication of Equals (SAE)

Compliant Standards

IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, Wi-Fi CERTIFIED, IEEE 802.11n, IEEE 802.3az, IEEE 802.11ac, IEEE 802.11ax

Aerial

Antenna

Internal

Antenna Qty

Internet of Things (IoT)

Internet of Things (IoT) Compatible

Yes

Communications Technology

Bluetooth Low Energy (LE), Zigbee

Expansion / Connectivity

Interfaces

2 x 1000Base-T - RJ-45 ¦ 1 x 1000Base-T (PoE+) - RJ-45 ¦ 1 x console - micro-USB

Miscellaneous

Compliant Standards

FCC, EN 60601-1-2, EN 60601-1-1, EMC 2014/30/EU, LVD 2014/35/EU, ISED, RED 2014/53/EU, IEC/EN 62368-1, IEC/EN 60950

Pricing Type

BTO

TAA Compliant

Yes

Power

Power Over Ethernet (PoE) Supported

PoE Class 3

Dimensions & Weight (Shipping)

Shipping Width

11.1 cm

Shipping Depth

5.4 cm

Shipping Height

16.7 cm

Shipping Weight

450 g

Manufacturer Warranty

Service & Support

Limited warranty - lifetime

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

5 - 93% (non-condensing)
