Product Form Factor
Rack-mountable - 2U
Built-in Devices
6 x fans
Front Accessible Bays Qty
8
CPU Upgradability
Upgradable
CPU Socket
LGA4710 Socket
Motherboard Name
R520G6SB
Installed Size
8192 GB (max)
Effective Memory Speed
6400 MHz
Rated Memory Speed
6400 MHz
Slots
32 (Total) / 32 (empty)
Interface Type
SATA 6Gb/s / SAS 4.0 / PCI Express (NVMe)
Graphics Processor
ASPEED AST2600
Video Interfaces
Mini DisplayPort
Ethernet Controller
Realtek RTL8211F
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
IPMI 2.0
Remote Management Controller
Aspeed AST2600
Slots
5 PCIe 5.0 x16 ¦ 2 Open Compute Project mezzanine (OCP) 3.0 (Mezzanine)
Interfaces
1 x USB 3.0 ¦ 1 x Mini DisplayPort ¦ 1 x LAN (Gigabit Ethernet) - RJ-45
Compliant Standards
FCC SDOC Class A, DOC-A, CB, LVD, RCM, VCCI, BSMI, NRTL, IC, sDoC, RoHS 2.0, RoHS
Power Redundancy Scheme
1+1
Voltage Required
AC 100-127/200-240 V
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
OS Provided
No operating system
Dimensions & Weight (Shipping)
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
5 - 95% (non-condensing)
