QNAP QSW-M2116P-2T2S

View all QNAP Network Switches - Visit the QNAP Store (QSW-M2116P-2T2S) - (ECE7766789)

QSW-M2116P-2T2S - Switch - Managed - 16 x 100/1000/2.5G (PoE+) + 2 x 10 Gigabit SFP+ + 2 x 100/1000/2.5/5/10G (PoE++) - desktop, rack-mountable - PoE++ (280 W)

Faster PoE and Backbone network transmission
Intelligent PoE functions for efficient, centralized PD management
Wi-Fi 6 experience for hotels
Deploy Wi-Fi 6 for mobile offices

FREE Delivery on orders over €250

2 Available to Ship
Order within 6Hrs 25Mins for: FREE Delivery (8 Jun or 9 Jun)

RRP ~~€1484.77~~

€889.75 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The QNAP QSW-M2116P-2T2S is a L2 PoE Managed Switch with sixteen 30-watt 2.5GbE PoE+ ports, two 90-watt 10GbE PoE++ ports. Offering a total power budget of 380 watts and two 10GbE SFP+ ports, the QSW-M2116P-2T2S not only enables a high-speed and high-power PoE network infrastructure for Wi-Fi 6 Access Points and Routers, but also provides backbone network uplinking capabilities. The QSS, QNAP Switch System with user-friendly web interface, helps IT administrators efficiently control Layer 2 and PoE networks, including wireless APs, IP Cameras and Digital Signage, core Switches and Servers. The QSW-M2116P-2T2S offers SMBs a cost-optimized and centrally managed LAN deployment solution.

Features Summary

Faster PoE and Backbone network transmission
QSW-M2116P-2T2S has two 10GbE ports and sixteen 2.5GbE PoE ports for connecting various high-speed powered devices. Two in-built 10GbE SFP+ ports can serve as uplink ports to the Internet and core networks or simply be connected to routers and LAN Fiber switches, improving LAN and WAN transmission efficiency. The switching capacity of QSW-M2116P-2T2S is 160Gbps, guaranteeing the full potential of each port.
Intelligent PoE functions for efficient, centralized PD management
The QSW-M2116P-2T2S supports intelligent PoE management functions, including scheduling, power supply prioritization, and power enabling and disabling. You can obtain real-time network connection status and power consumption information of PDs and configure PDs simultaneously to promote an energy-saving PoE network.
Wi-Fi 6 experience for hotels
Hotel staff can connect Wi-Fi 6 wireless APs and routers with the QSW-M2116P-2T2S to provide their customers with an all-new high-speed Wi-Fi 6 experience. The QSW-M2116P-2T2S can also supply PoE to powered devices of IP surveillance systems, Smart Access Control Systems and Self-help Kiosks.
Deploy Wi-Fi 6 for mobile offices
High speed mobility is the key to business growth. The QSW-M2116P-2T2S not only helps businesses to build a high-speed wireless LAN infrastructure, but also provides backbone network uplinking capabilities.

Specification Summary

Product Description

QNAP QSW-M2116P-2T2S - switch - 20 ports - Managed - rack-mountable

Device Type

Switch - 20 ports - Managed

Enclosure Type

Rack-mountable 1U

Subtype

10 Gigabit Ethernet

Ports

16 x 100/1000/2.5G (PoE+) + 2 x 10 Gigabit SFP+ + 2 x 100/1000/2.5/5/10G (PoE++)

Power Over Ethernet (PoE)

PoE++

PoE Budget

280 W

Performance

Switching capacity: 160 Gbps ¦ Non-blocking switching throughput: 80 Gbps

MAC Address Table Size

32K entries

Jumbo Frame Support

Yes

Features

Security slot (Kensington security lock compatible), port-based VLAN, firmware upgradable, loop prevention, port mirroring, ACL support, MAC address filtering, QoS, LACP, IGMP snooping, Jumbo Frames support, auto-negotiation, flow control, web-based management

Compliant Standards

IEEE 802.3az, IEEE 802.3x, IEEE 802.3, IEEE 802.3u, IEEE 802.1ab (LLDP), IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3an, IEEE 802.3bz, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt

Power

AC 100-240 V (50/60 Hz)

Dimensions (WxDxH)

28.5 cm x 23.48 cm x 4.35 cm

Weight

2.08 kg

Manufacturer Warranty

2-year warranty

Specifications

EAN / GTIN:

4713213518861

General

Device Type

Switch - 20 ports - Managed

Enclosure Type

Desktop, rack-mountable 1U

Subtype

10 Gigabit Ethernet

Ports

16 x 100/1000/2.5G (PoE+) + 2 x 10 Gigabit SFP+ + 2 x 100/1000/2.5/5/10G (PoE++)

Power Over Ethernet (PoE)

PoE++

PoE Budget

280 W

Performance

Switching capacity: 160 Gbps ¦ Non-blocking switching throughput: 80 Gbps

MAC Address Table Size

32K entries

Jumbo Frame Support

Yes

Features

Compliant Standards

Status Indicators

Power, port transmission speed, link/activity, status

Expansion / Connectivity

Interfaces

16 x 2.5Gbit LAN RJ-45 PoE+ - 30 W ¦ 2 x 10Gbit LAN SFP+ ¦ 2 x 10Gbit LAN RJ-45 PoE++ - 90 W ¦ 1 x management RJ-45

Power

Power Device

Internal power supply

Voltage Required

AC 100-240 V (50/60 Hz)

Power Consumption Operational

350 Watt

Miscellaneous

Included Accessories

Power cord, rack mount kit, 4 rubber feet

Rack Mounting Kit

Included

Compliant Standards

FCC, VCCI, BSMI, Class A

Dimensions & Weight

Width

28.5 cm

Depth

23.48 cm

Height

4.35 cm

Weight

2.08 kg

Dimensions & Weight (Shipping)

Shipping Weight

2.13 kg

Manufacturer Warranty

Service & Support

Limited warranty - 2 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

5 - 95% (non-condensing)
