Startech MSA Uncoded Compatible QSFP+ Module, 40GB

Images Manuals

Startech MSA Uncoded Compatible QSFP+ Module, 40GBASE-SR4, 40GbE Multi Mode (MMF) Fiber Optic Transceiver, 40GE Gigabit Ethernet QSFP+, MPO Connector,

Images for illustrative purposes

Startech MSA Uncoded Compatible QSFP+ Module, 40GBASE-SR4, 40GbE Multi Mode (MMF) Fiber Optic Transceiver, 40GE Gigabit Ethernet QSFP+, MPO Connector,

Name: Startech MSA Uncoded Compatible QSFP+ Module, 40GBASE-SR4, 40GbE Multi Mode (MMF) Fiber Optic Transceiver, 40GE Gigabit Ethernet QSFP+, MPO Connector,
Brand: STARTECH.COM
SKU: ECE4631427
Price: 47.58 EUR
Availability: OutOfStock

View all STARTECH.COM Repeaters | Tranceivers - Visit the STARTECH.COM Store (QSFP40SR4ST) - (ECE4631427)

Startech MSA Uncoded Compatible QSFP+ Module, 40GBASE-SR4, 40GbE Multi Mode (MMF) Fiber Optic Transceiver, 40GE Gigabit Ethernet QSFP+, MPO Connector, 100m, 850nm, DDM, 40 Gbps QSFP+ - Lifetime Warranty (QSFP40SR4ST) - QSFP+ transceiver module - 40GbE - 4

FREE Delivery on orders over €250

0 Available to Ship
Restock 19-Jun-2026 Estimated, Out of Stock Prices are Estimated.

€47.58 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

40 Gbps | Multi Mode Fiber | MPO | 150 m (492 ft) | Lifetime Warranty. The QSFP40SR4ST is an MSA compliant fiber QSFP+ transceiver that's designed, programmed and tested to work with 40GBASE-SR4 compatible MSA switches and routers. The QSFP+ transceiver module supports a maximum distance of up to 150 m (492 ft) and delivers dependable 40 GbE connectivity over fiber cabling.

Technical Specifications:

Wavelength: 850 nm

Maximum Data Transfer Rate: 40 Gbps

Type: Multi Mode Fiber

Connection Type: MPO Connector

Maximum Transfer Distance: 150 m (492 ft)

MTBF: 1,489,426 hours

Power Consumption: Less than 0.7 Watts

DDM: Yes

This QSFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.

Specification Summary

Product Description

Device Type

QSFP+ transceiver module - MPO multi-mode

Form Factor

Plug-in module

Cabling Type

40GBASE-SR4

Data Transfer Rate

40 Gbps

Optical Wave Length

850 nm

Data Link Protocol

40GbE

Max Transfer Distance

150 m

Dimensions (WxDxH)

1.84 cm x 7.2 cm x 0.85 cm

Weight

40 g

Manufacturer Warranty

Limited lifetime warranty

Designed For

P/N: PEX40GQSFDPI, PEX40GQSFPI

Specifications

EAN / GTIN:

0065030873567

General

Device Type

QSFP+ transceiver module

Form Factor

Plug-in module

Colour

Silver

Networking

Connectivity Technology

Wired

Cabling Type

40GBASE-SR4

Data Link Protocol

40GbE

Data Transfer Rate

40 Gbps

Optical Wave Length

850 nm

Max Transfer Distance

150 m

Features

Full duplex mode, Digital Optical Monitoring (DOM) support, Digital Diagnostics Monitoring (DDM)

Compliant Standards

IEEE 802.3ba

Expansion / Connectivity

Interfaces

1 x Ethernet 40GBASE-SR4 - MPO multi-mode

Miscellaneous

MTBF

1,489,426 hours

Compliant Standards

UL, FCC, RoHS, MSA

Dimensions & Weight

Width

1.84 cm

Depth

7.2 cm

Height

0.85 cm

Weight

40 g

Manufacturer Warranty

Service & Support

Limited warranty - lifetime

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

70 °C

Humidity Range Operating

5 - 95%

Compatibility Information

Designed For

P/N: PEX40GQSFDPI, PEX40GQSFPI
