Datalogic QuickScan QD2590

Name: Datalogic QuickScan QD2590
Brand: DATALOGIC
SKU: MMECB00166
Price: 96.95 EUR
Availability: InStock

View all DATALOGIC Barcode Scanners - Visit the DATALOGIC Store (QD2590-BK) - (MMECB00166)

Model: Datalogic QuickScan

QuickScan QD2590 - barcode scanner

Improve performance with user friendly feedback
Connect, configure, use
Perform, perform, perform
Don't underestimate the versatility

FREE Delivery on orders over €250

**Note: PLEASE CHECK, most manufacturers do not provide cables with Handheld Scanners

23 Available to Ship
Order within 15Hrs 13Mins for: Delivery (8 Jun or 9 Jun)

€96.95 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The QuickScan QD2500 imager from Datalogic is an entry level 2D corded handheld scanner that punches well above its weight when it comes to performance. It is the robust and reliable companion in the retail sector for your POS checkout, built for many years of continued service. It effortlessly reads a full range of barcodes, be they damaged, hard to read, or poorly printed.

Specification Summary

Product Description

Datalogic QuickScan QD2590 - barcode scanner

Type

Barcode scanner - handheld - keyboard wedge, RS-232, USB - decoded

Colour

Black

Minimum Bar Width

3 mil

Scan Element Type

2D imager - Red LED

Sensor Resolution

1280 x 800

Scan Speed

60 frames / sec

Connectivity Technology

Wired

Power

DC 5 V

Dimensions (WxDxH)

6.8 cm x 12.6 cm x 14.8 cm

Weight

145 g

Manufacturer Warranty

5-year warranty

Specifications

General

Type

Barcode scanner - handheld

Colour

Black

Barcode

Interface Type

Keyboard wedge, RS-232, USB

Minimum Bar Width

3 mil

Scan Element Type

2D imager - Red LED

Sensor Resolution

1280 x 800

Light Source Wave Length

617 nm

Scan Mode

Single-pass

Frame Rate

60 frames / sec

Max Working Distance

41 cm

Skew (Degrees)

Pitch (Degrees)

Print Contrast Signal (PCS)

15%

Decode Capability

EAN/JAN, GS1 DataBar, QR code, MaxiCode, Aztec code, MicroPDF417, Postnet, PDF417, Data Matrix, PLANET, Australian Post, British Post, Canadian Post, China Post, Japanese Post, Kix (Netherlands) Post, Korea Post, MacroPDF417, Royal Mail, Micro QR code, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Expanded Stacked, GS1 DataBar Composites, GS1 DataBar Stacked, China Han Xin Code, UPC A Composite, UPC E Composite

TTL Decoding

Decoded

Connectivity Technology

Wired

OK Notification

Beeper, LED indicator

Features

Digimarc Barcode Technology, Green Spot technology

Expansion / Connectivity

Interfaces

1 x RS-232 ¦ 1 x keyboard wedge ¦ 1 x USB

Miscellaneous

Compliant Standards

RoHS, IP52

Power

Voltage

DC 5 V

Electric Current Required

450 mA (typical), 90 mA (standby)

Software

Software Included

Datalogic Aladdin

Dimensions & Weight

Width

6.8 cm

Depth

12.6 cm

Height

14.8 cm

Weight

145 g

Manufacturer Warranty

Service & Support

Limited warranty - 5 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

50 °C

Humidity Range Operating

0 - 95% (non-condensing)

Drop Specification

1.5 m to concrete
