EAN / GTIN:
4712856277586
Device Type
UPS - rack-mountable / external
UPS Technology
Line interactive
Input Voltage
AC 220/230/240 V
Input Voltage Range
AC 159 - 288 V
Input Voltage Range (Adjustable)
AC 151 - 302 V
Frequency Provided
50/60 Hz ± 1%
Frequency Required
50/60 Hz ± 3Hz
Input Connectors
1 x power IEC 60320 C20
Power Output Connectors Details
6 x power IEC 60320 C13 (UPS and surge) ¦ 2 x power IEC 60320 C19 (UPS and surge)
Output Voltage
AC 220/230/240 V ± 5% - 50/60 Hz
Power Capacity
2200 Watt / 2200 VA
Dataline Surge Protection
Network - RJ-45 - 1 input line / 1 output line
Surge Energy Rating
2430 Joules
Circuit Protection
Circuit breaker
Run Time (Up To)
3 min at full load ¦ 11.4 min at half load
Remote Management Interface
RS-232, USB
Interfaces
1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x management (USB) - 4 pin USB Type B ¦ 1 x EPO (emergency power off)
Expansion Slots
1 (total) / 1 (free) x Expansion Slot
Cables Included
Serial cable - external ¦ EPO cable - external ¦ USB cable - external ¦ Power cable 2.4 m
Rack Mounting Kit
Included
Equipment Protection Value
100000 Euros
Features
Audible alarm, audible alarm, emergency power off, LCD display, Automatic Voltage Regulation (AVR), LED indicators, GreenPower UPS Technology, overload protection, hot-swappable batteries, start on battery, generator compatible
Compliant Standards
FCC Class B certified, UL, VCCI, RoHS, RCM
Software / System Requirements
Software Included
PowerPanel Business Edition
Sustainability Information
Service & Support
Limited warranty - batteries - 2 years
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
0 - 95% (non-condensing)
Dimensions & Weight (Shipping)
