Zyxel PoE 12

View all ZYXEL Power Accessories - Visit the ZYXEL Store (POE12-60W-GB0101F) - (MMECC00131)

PoE 12 - PoE injector - 60 Watt

Efficient power delivery
Simple installation

FREE Delivery on orders over €250

3 Available to Ship
Order within 20Hrs 29Mins for: Delivery (9 Jun or 10 Jun)

€59.89 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

ZyXEL PoE-12 is a single-port Power over Ethernet (PoE) Injector that infuses and transmits electricity through unused pairs (4/5 and 7/8) in CAT-5 Ethernet cables, while data flows are carried by the other pairs (1/2 and 3/6). As such both power and data can be delivered to PoE devices (PD) via a single CAT-5 Ethernet cable without extra power supply.

With the PoE-12, non-PoE switches can now power IEEE802.3af compliant PoE devices through an effective single CAT-5 Ethernet cable link up to 100m in length.

In other words, users can install any IEEE 802.3af compliant PoE devices like WLAN access points or IP surveillance cameras with more freedom. Unlike traditional solutions, the PoE-12 can now take advantage of the effortless connectivity in challenging places, such as ceiling or top of wall, without laying power cables. It means that the devices are now untied from power outlets for maximum flexibility.

The PoE-12 is easy to use and needs no configuration. Since only simple inbound and outbound cable plugging is required, installation is straightforward and can be performed by users without power cabling expertise or expense.

Specification Summary

Product Description

Zyxel PoE 12 - PoE injector - 60 Watt

Device Type

PoE injector - external

Weight

278 g

Input Voltage

AC 100-240 V

Power Capacity

60 Watt

Output connectors

2 x RJ-45

Dimensions (WxDxH)

14 cm x 6.5 cm x 3.85 cm

Specifications

EAN / GTIN:

4718937621675

General

Device Type

PoE injector - external

Power Device

Input Voltage

AC 100-240 V

Frequency Required

50/60 Hz

Power Consumption Operational

74.7 Watt

Power Output Connectors Details

2 x RJ-45

Max Electric Current

2 A

Power Capacity

60 Watt

Surge Suppression

Yes

Expansion / Connectivity

Interfaces

2 x 1/2.5/5/10 Gigabit LAN (PoE++) - RJ-45

Miscellaneous

Cables Included

Power cable

MTBF

1,892,473 hours

Features

6 kV ESD protection (Contact), 6 kV surge protection, 8 kV ESD protection (Air)

Compliant Standards

IEEE 802.3bt, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3bz, IEEE P802.3an

Environmental Parameters

Min Operating Temperature

-10 °C

Max Operating Temperature

40 °C

Humidity Range Operating

5 - 90% (non-condensing)

Dimensions & Weight

Width

14 cm

Depth

6.5 cm

Height

3.85 cm

Weight

278 g

Dimensions & Weight (Shipping)

Shipping Width

16.8 cm

Shipping Depth

14.2 cm

Shipping Height

4.7 cm

Shipping Weight

1.12 kg
