HPE ProLiant DL345 Gen11 - rack-mountable EPYC 901

Images Manuals

Images for illustrative purposes

HPE ProLiant DL345 Gen11

Name: HPE ProLiant DL345 Gen11
Brand: HPE
SKU: MMECO42918
Price: 11239.75 EUR
Availability: InStock

View all HPE Servers - Visit the HPE Store (P81837-425) - (MMECO42918)

Model: HPE ProLiant

ProLiant DL345 Gen11 - rack-mountable EPYC 9015 3.6 GHz - 64 GB - SSD 2 x 960 GB

Efficient management
High-speed performance
Flexible storage options
Advanced connectivity
Energy-efficient design

FREE Delivery on orders over €250

SPO - THIS IS A SPECIAL ORDER ITEM AND CANNOT BE RETURNED AS UNWANTED OR CANCELLED. **Note: PLEASE CHECK, MONITOR NOT INCLUDED IN MOST PCs.

1 Available to Ship
Order within 15Hrs 17Mins for: FREE Delivery (8 Jun or 9 Jun)

RRP ~~€12988.36~~

€11239.75 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The HPE ProLiant DL345 Gen11 server is a scalable 2U 1P solution that delivers exceptional compute performance and large capacity storage options at 1P economics. Powered by 4th Generation AMD EPYC Processors with up to 96 cores, increased memory bandwidth, high-speed PCIe Gen5 I/O and EDSFF storage, up to 20LFF/ 34SFF, and up to 4 GPUs at the front, this server is a superb single-socket 2U solution for your data-intensive workloads. Enhanced security features with the HPE silicon root of trust are built into the firmware, creating a digital fingerprint for the AMD Secure Processor to validate safe operation before boot. The HPE DL345 Gen11 server provides impressive storage performance and options for dataintensive workloads like software-defined storage, video transcoding, and virtualized apps.

Specification Summary

Product Description

HPE ProLiant DL345 Gen11 - rack-mountable EPYC 9015 3.6 GHz - 64 GB - SSD 2 x 960 GB

Type

Server - rack-mountable

Height (Rack Units)

Localisation

Region: Europe, Middle East, Africa

Server Scalability

1-way

Processor

1 x AMD EPYC 9015 / 3.6 GHz (up to 4.1 GHz, (8-core)

Cache Memory

64 MB L3 Cache

Cache Per Processor

64 MB

RAM

64 GB (installed) / 3 TB (max) - DDR5 SDRAM

Storage Controller

RAID (Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)) - OCP 3.0 (HPE MR416i-p Gen11 SPDM)

Server Storage Bays

Hot-swap 3.5"

Hard Drive

2 x SSD 960 GB - SATA 6Gb/s

Optical Storage

No optical drive

Video Memory

16 MB

Networking

1GbE

Power Redundancy

Yes

Dimensions (WxDxH)

44.8 cm x 66.3 cm x 8.75 cm

Weight

16.97 kg

Manufacturer Selling Program

HPE Smart Choice

Environmental Standards

ENERGY STAR Qualified

Manufacturer Warranty

Limited warranty - parts and labour - 3 years - on-site - response time: next business day

Specifications

EAN / GTIN:

0190017795690

General

Type

Server

Product Form Factor

Rack-mountable - 2U

Built-in Devices

Led panel

Embedded Security

Trusted Platform Module (TPM 2.0) Security Chip

Server Scalability

1-way

Hot-Swap Bays Qty

Localisation

Region: Europe, Middle East, Africa

Processor / Chipset

CPU

AMD EPYC 9015

Clock Speed

3.6 GHz

Max Turbo Speed

4.1 GHz

Number of Cores

8-core

CPU Qty

Max CPU Qty

CPU Upgradability

Upgradable

Cache Memory

Installed Size

L3 Cache - 64 MB

Cache Per Processor

64 MB

RAM

Installed Size

64 GB (installed) / 3 TB (max)

Technology

DDR5 SDRAM

Effective Memory Speed

3000 MHz

Rated Memory Speed

3200 MHz

Form Factor

DIMM 288-pin

Slots

12 (Total) / 10 (empty)

Features

HPE SmartMemory, registered

Configuration Features

2 x 32 GB

Hard Drive

Type

SSD

Capacity

2 x 960 GB

Interface Type

SATA 6Gb/s

Features

HPE Multi Vendor, Read Intensive

Storage Controller

Type

1 x RAID - OCP 3.0

Controller Interface Type

Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)

Storage Controller Name

HPE MR416i-p Gen11 SPDM

Channel Qty

RAID Level

RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60

Buffer Size

8 GB

Optical Storage

Type

No optical drive

Monitor

Monitor Type

None.

Graphics Controller

Video Memory

16 MB

Video Interfaces

VGA

Networking

Interface (Bus) Type

Open Compute Project mezzanine (OCP) 3.0

Ethernet Ports

4 x Gigabit Ethernet

Ethernet Controller

Broadcom BCM5719

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet

Remote Management Protocol

IPMI 2.0, SNMP 3

Remote Management Controller

Integrated Lights-Out 6

Features

Wake on LAN (WoL), PXE support

Expansion / Connectivity

Bays

8 (total) / 6 (free) x hot-swap 3.5" LFF

Slots

2 (total) / 2 (free) x PCIe 5.0 x16 - half-length, full-height (x16 mode) ¦ 2 (total) / 0 (free) x Open Compute Project mezzanine (OCP) 3.0

Interfaces

1 x HPE iLO (1 in front) (service port) ¦ 5 x USB 3.2 Gen 1 (1 front, 2 rear, 2 internal) ¦ 1 x VGA ¦ 4 x LAN (Gigabit Ethernet)

Miscellaneous

Included Accessories

6 x standard fans, HPE standard heatsink, HPE Easy Install Rail 2 Kit

Compliant Standards

WEEE, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1, UEFI 2.7, SMBIOS 3.1, Redfish API, AES, Triple DES, UEFI Class 3, Active Directory v1.0, APML 1.0

Manufacturer Selling Program

HPE Smart Choice

Power

Device Type

Power supply - hot-plug

Power Redundancy

Yes

Power Redundancy Scheme

1+1

Installed Qty

Max Supported Qty

Voltage Required

AC 100-120/200-240 V

Power Provided

1000 watt

80 PLUS Certification

80 PLUS Titanium

Sustainability Information

ENERGY STAR Certified

Yes

ENERGY STAR Version

4.0

Manufacturer Warranty

Service & Support

Limited warranty - parts and labour - 3 years - on-site - response time: next business day

Dimensions & Weight

Width

44.8 cm

Depth

66.3 cm

Height

8.75 cm

Weight

16.97 kg

Dimensions & Weight (Shipping)

Shipping Width

60 cm

Shipping Depth

91.77 cm

Shipping Height

27 cm

Environmental Parameters

Min Operating Temperature

10 °C

Max Operating Temperature

35 °C

Humidity Range Operating

8 - 90% RH (non-condensing)
