EAN / GTIN:
0190017767772
Product Form Factor
Rack-mountable - 1U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Region: Europe
CPU
Intel Xeon Silver 4514Y
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology
Installed Size
L3 Cache - 30 MB
Cache Per Processor
30 MB
Installed Size
64 GB (installed) / 2.04 TB (max)
Effective Memory Speed
2800 MHz
Rated Memory Speed
2800 MHz
Slots
16 (Total) / 14 (empty)
Features
Registered, HPE SmartMemory, 8-channel memory architecture
Configuration Features
2 x 32 GB
Controller Interface Type
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Storage Controller Name
HPE MR408i-o Gen11 SPDM
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10, RAID 50, RAID 60
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5720
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
IPMI 2.0, SNMP 3
Remote Management Controller
Integrated Lights-Out 6
Features
ACPI support, PXE support, Wake on LAN (WoL)
Bays
8 (total) / 6 (free) x hot-swap 2.5" SFF
Slots
2 (total) / 2 (free) x PCIe 5.0 x16 - full-length, full-height (x16 mode) ¦ 1 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode)
Interfaces
1 x HPE iLO (1 in front) (service port) ¦ 3 x USB 3.2 Gen 1 (1 front, 2 rear) ¦ 1 x USB 2.0 ¦ 1 x VGA ¦ 2 x LAN (Gigabit Ethernet)
Included Accessories
7 x standard fans
Compliant Standards
AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.3
Manufacturer Selling Program
HPE Smart Choice
Device Type
Power supply - hot-plug
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
OS Provided
No operating system
OS Certified
Microsoft Windows Server 2019, Microsoft Windows Server 2022, VMware ESXi 7.0 update 3, VMware ESXi 8.0, VMware ESXi 8.0 update 1, Red Hat Enterprise Linux 8.6, Red Hat Enterprise Linux 9.0, SUSE Linux Enterprise Server 15 SP4, Ubuntu 22.04 LTS, CentOS
Sustainability Information
ENERGY STAR Certified
Yes
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
