Overview

Range/Series Overview


IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The Eaton Tripp Lite Series DisplayPort Cable with Latching Connectors is designed to provide connectivity for modern displays. With a maximum resolution of 7680 x 4320 at 60 Hz, this cable enables stunning visuals and supports HDR for an enhanced viewing experience. The double shielded design ensures EMI/RFI protection, allowing for stable signal transmission without interference. The 20 ft (6.1 m) length offers flexibility in placement while adhering to DisplayPort 1.4 standards for compatibility.

This cable features High Bit Rate 3 (HBR3) technology and supports Chroma subsampling (4:4:4) and 24-bit True Color, ensuring vibrant colors and sharp images. With a bandwidth capacity of up to 32.4 Gbps, the Eaton Tripp Lite Series is suitable for a variety of applications, from gaming to professional multimedia. Compliance with RoHS, WEEE, and HDCP 2.2 standards underscores its commitment to quality and environmental responsibility.


Specification Summary

Product Description
Eaton Tripp Lite Series DisplayPort Cable with Latching Connectors (M/M), 8K 60 Hz, HDR, HBR3, 4:4:4, HDCP 2.2, 20 ft. (6.1 m), Black - DisplayPort cable - DisplayPort to DisplayPort - 6.1 m
Type
DisplayPort cable
Technology
Double shielded
Features
Passive cable, 8K UHD (7680 x 4320) support, EMI/RFI protection, maximum resolution 7680x4320 at 60Hz, HDR support, bidirectional, High Bit Rate 3 (HBR3), Chroma subsampling (4:4:4), BT.2020, 24-bit True Color, up to 32.4 Gbps bandwidth
Length
6.1 m
Connector
20 pin DisplayPort - male
Connector (Second End)
20 pin DisplayPort - male
Compliant Standards
DisplayPort 1.4
Colour
Black
Package Type
Polybag
Manufacturer Warranty
Limited lifetime warranty
Designed For
P/N: B156-002-8K, B156-002-HDMI, B156E-002-8K-K, B156E-003-8K-K

Specifications

EAN / GTIN:
0037332290953
General
Type
DisplayPort cable
Technology
Double shielded
Jacket Material
PVC
American Wire Gauge (AWG)
26
Plated Connector
Gold
Features
Passive cable, 8K UHD (7680 x 4320) support, EMI/RFI protection, maximum resolution 7680x4320 at 60Hz, HDR support, bidirectional, High Bit Rate 3 (HBR3), Chroma subsampling (4:4:4), BT.2020, 24-bit True Color, up to 32.4 Gbps bandwidth
Length
6.1 m
Outside Diameter
7.3 mm
Colour
Black
Weight
390 g
Connectivity
Connector
20 pin DisplayPort - male
Connector (Second End)
20 pin DisplayPort - male
Miscellaneous
Compliant Standards
DisplayPort 1.4, RoHS, WEEE, HDCP 2.2, UKCA
Package Details
Polybag
Dimensions & Weight (Shipping)
Shipping Width
35.6 cm
Shipping Depth
1.27 cm
Shipping Height
43.2 cm
Shipping Weight
390 g
Service & Support
Limited lifetime warranty
Compatibility Information
Designed For
P/N: B156-002-8K, B156-002-HDMI, B156E-002-8K-K, B156E-003-8K-K
