Device Type
Solid state drive - internal
NAND Flash Memory Type
3D triple-level cell (TLC)
Interface
U.2 PCIe 5.0 x4 (NVMe)
Features
NVM Express (NVMe) 2.0b, power loss data protection, Enterprise Data Path Protection, Redundant Array of Independent NAND, Firmware Activate without Reset, Secure Erase function, Secure Boot, Active Garbage Collection, TRIM support, NVMe standard Self-Monitoring and Reporting Technology ((SMART), Hardware Root of Trust, Secure Signed Firmware, 232-layer TLC NAND technology, Open Compute Project 2.0, Security Protection Data Model (SPDM), S.M.A.R.T.
Drive Writes Per Day (DWPD)
1
Drive Class
Enterprise, Read Intensive
Internal Data Rate
14000 MBps (read) / 6000 MBps (write)
4KB Random Read
3000000 IOPS
4KB Random Write
300000 IOPS
Non-Recoverable Errors
1 per 10^17
Interfaces
1 x U.2 PCIe 5.0 x4 (NVMe)
Power Consumption
18 Watt (sequential read) ¦ 16 Watt (sequential write)
Compliant Standards
FCC, UL/cUL, BSMI, RCM, WEEE, TUV, VCCI, IC, Morocco, UkrSEPRO, UKCA
Package Details
Cardboard box
Dimensions & Weight (Shipping)
Service & Support
Limited warranty - 5 years / 7008 TBW
Min Operating Temperature
0 °C
Max Operating Temperature
70 °C
