Range/Series Overview
IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.
10/100/1000 Mbps Copper RJ45 100 m (328 ft) Lifetime Warranty. The MASFP1GBSXST is a Cisco Meraki MA-SFP-1GB-SX compatible copper transceiver module that has been designed, programmed and tested to work with Cisco Meraki brand switches and routers. It delivers dependable 1GbE (1000 Mbps) connectivity over copper cable, for 10BASE-T, 1000BASE-T and 100BASE-TX compliant networks, with a maximum distance of up to 100 m (328 ft).
Technical Specifications:
Maximum Data Transfer Rate: 1000 Mbps
Type: Copper
Connection Type: RJ45 Connector
Maximum Transfer Distance: 100 m (328 ft)
MTBF: 4,655,371 hours
Power Consumption: Less than 1.3 Watts
Digital Diagnostics Monitoring (DDM): No
This SFP copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
Specification Summary
Product Description
Startech Cisco Meraki MA-SFP-1GB-TX Compatible SFP Module, 1000BASE-T, SFP to RJ45 Cat6/Cat5e, 10/100/1000 Mbps, RJ-45 (Copper) 100m, Cisco Meraki MS225, MX400, MS250, 1GbE Mini GBIC - Lifetime Warranty (MASFP1GBTXST) - SFP (mini-GBIC) transceiver module - 1GbE
Device Type
SFP (mini-GBIC) transceiver module - RJ-45
Form Factor
Plug-in module
Data Transfer Rate
1 Gbps
Max Transfer Distance
100 m
OEM Manufacturer Equivalent Part Number
Cisco Meraki MA-SFP-1GB-TX
Dimensions (WxDxH)
1.37 cm x 6.8 cm x 1.38 cm
Manufacturer Warranty
Limited lifetime warranty
