Range/Series Overview
IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.1000 Mbps (1 Gbps) | Multi Mode Fiber | LC | 550 m (1804 ft) | Lifetime Warranty. The MASFP1GBSXST is a Cisco Meraki MA-SFP-1GB-SX compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco Meraki brand switches and routers. It delivers dependable 1GbE (1000 Mbps) connectivity over fiber cable, for 1000BASE-SX compliant networks, with a maximum distance of up to 550m (1804 ft).
Technical Specifications:
Wavelength: 850nm
Maximum Data Transfer Rate: 1.25 Gbps
Type: Multi Mode Fiber
Connection Type: LC Connector
Maximum Transfer Distance: 550m (1804 ft)
MTBF: 1,967,709 hours
Power Consumption: Less than 1.2 Watts
Digital Diagnostics Monitoring (DDM): Yes
This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
Features Summary
- Reliable connectivity
The Cisco Meraki MA-SFP-1GB-SX supports robust wired connectivity through its Ethernet 1000Base-SX cabling type, ensuring consistent performance for demanding networking tasks. - Enhanced diagnostic capabilities
This module features Digital Diagnostics Monitoring (DDM) and Digital Optical Monitoring (DOM), providing critical insights into module performance and helping to maintain optimal operation. - Wide environmental range
With an operational temperature range from 0°C to 70°C and humidity levels of 5% to 95%, this module is capable of performing reliably in diverse conditions. - Efficient data transmission
The full duplex mode allows for simultaneous two-way data transmission, significantly improving overall network efficiency. - Compliance with industry standards
The module meets several standards including IEEE 802.3z, UL, FCC, RoHS, and MSA, ensuring quality and compatibility within professional networking environments.
Specification Summary
Product Description
Startech Cisco Meraki MA-SFP-1GB-SX Compatible SFP Module, 1000BASE-SX, 1GbE MMF Optic Transceiver, LC Connector, 550m, 850nm, DDM, Cisco Meraki MS225, MX400, Mini GBIC Transceiver - Lifetime Warranty (MASFP1GBSXST) - SFP (mini-GBIC) transceiver module - 1GbE
Device Type
SFP (mini-GBIC) transceiver module - LC multi-mode
Form Factor
Plug-in module
Data Transfer Rate
1.25 Gbps
Optical Wave Length
850 nm
Max Transfer Distance
550 m
OEM Manufacturer Equivalent Part Number
Cisco Meraki MA-SFP-1GB-SX
Dimensions (WxDxH)
1.37 cm x 5.66 cm x 1.25 cm
Manufacturer Warranty
Limited lifetime warranty
