Range/Series Overview
IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.
10 Gbps | Single Mode Fiber | LC | 10 km (6.2 mi) | Lifetime Warranty. The MASFP10GBLR is a Cisco Meraki MA-SFP-10GB-LR compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco Meraki brand switches and routers. It delivers dependable 10GbE connectivity over fiber cable, for 10GBASE-LR compliant networks, with a maximum distance of up to 10 km (6.2 mi).
Technical Specifications:
Wavelength: 1310nm
Maximum Data Transfer Rate: 10 Gbps
Type: Single Mode Fiber
Connection Type: LC Connector
Maximum Transfer Distance: 10 km (6.2 mi)
MTBF: 2,104,865 hours
Power Consumption: Less than 1.2 Watts
Digital Diagnostics Monitoring (DDM): Yes
This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
Specification Summary
Product Description
Startech Cisco Meraki MA-SFP-10GB-LR Compatible SFP+ Module, 10GBASE-LR, 10GbE SMF Optic Transceiver, Gigabit Ethernet SFP+, LC Connector, 10km 1310nm DDM, Cisco Meraki MS225, MX400 - Lifetime Warranty (MASFP10GBLR) - SFP+ transceiver module - 10GbE
Device Type
SFP+ transceiver module - LC single-mode
Form Factor
Plug-in module
Data Transfer Rate
10 Gbps
Optical Wave Length
1310 nm
Max Transfer Distance
10 km
OEM Manufacturer Equivalent Part Number
Cisco Meraki MA-SFP-10GB-LR
Dimensions (WxDxH)
1.39 cm x 5.84 cm x 1.26 cm
Manufacturer Warranty
Limited lifetime warranty
