Device Type
Host bus adapter
Form Factor
Plug-in card - low profile
Interface (Bus) Type
PCI Express 4.0 x8
PCI Specification Revision
PCIe 4.0
Ports
64Gb Fibre Channel Gen 7 (Short Wave) x 1
Connectivity Technology
Wired
Cabling Type
Fibre Channel
Data Link Protocol
64Gb Fibre Channel Gen 7 (Short Wave), 32Gb Fibre Channel Gen 7 (Short Wave), 16Gb Fibre Channel (Short Wave)
Fibre Channel
FC-DA, FC-DA-2, FC-FS, FC-FS-3, FC-FS-4, FC-FS-5, FC-GS-2, FC-GS-3, FC-GS-4, FC-GS-5, FC-GS-6, FC-GS-7, FC-LS-2, FC-LS-3, FC-LS-5, FC-MI, FC-NVMe, FC-NVMe with AM1, FC-PH, FC-PH-2, FC-PH-3, FC-PI, FC-PI-2, FC-PI-3, FC-PI-4, FC-PI-5, FC-PI-6, FC-PI-7, FC-Tape, FCP-2, FCP-3, FCP-4, SBC-3, SPC-3, SPC-4, SSC-2, SSC-3, SSC-4
Data Transfer Rate
28.9 Gbps
Interfaces
1 x 64Gb Fibre Channel Gen 7 (Short Wave) - LC
Included Accessories
Low-profile bracket, standard bracket
Compliant Standards
OM4, OM5, OM3, RCM Class A, BSMI, China RoHS, RoHS, LVD, EU RoHS, VCCI Class A, KCC Class A, FCC Class A certified, ICES Class A, UL, CSA, BSMI Class A, UKCA
Software / System Requirements
OS Required
Microsoft Windows, Oracle Linux, Oracle Solaris, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vShpere
Min Operating Temperature
0 °C
Max Operating Temperature
55 °C
Humidity Range Operating
5 - 95% (non-condensing)
