EAN / GTIN:
8806095638416
Product Type
LED-backlit LCD flat panel display
Power Consumption (Max)
363 watt
Power Consumption Operational
197 watt
Commercial Use
Yes - digital signage
Operating System
Tizen OS 7.0
Video Processor
Quantum 4K Lite
Sensors
Ambient light sensor (ALS), temperature sensor
Modes
Director Mode, DICOM Simulation Mode, landscape mode, portrait mode
Picture Enhancements
Mega Dynamic Contrast Ratio, 72% Colour Gamut NTSC, Intelligent UHD upscaling, Dynamic Crystal Color
Design
Even Bezel Design, Slim Design
Enclosure Colour
Slate black
LCD Display Technology
VA
Display Format
4K UHD (2160p)
LCD Backlight Technology
LED backlight
Coating
25% Glass Haze, anti-glare
Image Contrast Ratio
5500:1
Viewing Angle
178 degrees
Viewing Angle (Vertical)
178 degrees
Commercial Features
SMART Signage Platform, Samsung VXT CMS, Home UI, MagicInfo S10 Player, Auto Source Switching & Recovery, Auto Level, Signage New Home, Custom Home, upgradable web-engine, Tizen Enterprise Platform, VMWare, Microsoft 365
Operation Hours / Days
24 / 7
Features
SSSP 10.0, Smart Calibration, Workspace, Center IR
Flat Panel Mount Interface
600 x 400 mm
Configuration
ARM Cortex-A73 Quad-Core ( 1.6 GHz ) 16 GB (available 10 GB)
Output Power / Total
20 watt
Network & Internet Multimedia
Connectivity
Wi-Fi, Bluetooth, LAN
Encryption
WPA2-Enterprise, WPA3-Personal, EAP-TLS, EAP-TTLS, EAP-PEAP
Connect & Share
Samsung Smart View+
Connector Type
3 x HDMI input ¦ DisplayPort input ¦ 2 x USB 2.0 ¦ Audio line-out ¦ RS-232 input ¦ RS-232 output ¦ LAN
Cables Included
RS-232C (IN) adapter
Compliant Standards
EMC Class A, HDCP 2.2, Safety 60950-1, Safety 62368-1, IP5X
Sustainability Information
EPEAT Compliant
EPEAT Bronze
ENERGY STAR Certified
Yes
Power Device
Power supply
Input Voltage
AC 100-240 V (50/60 Hz)
Power Consumption Sleep
0.5 watt
Dimensions & Weight (Shipping)
Height (Shipping)
139.5 cm
Weight (Shipping)
77.2 kg
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 80% (non-condensing)
