Samsung IE015R-F IER Series LED display unit - for

Images Manuals

Samsung IE015R-F IER Series LED display unit

Images for illustrative purposes

Samsung IE015R-F IER Series LED display unit

View all SAMSUNG Digital Signage | Large Displays - Visit the SAMSUNG Store (LH015IERKFS/EN) - (WCELH015IERKFSEN)

IE015R-F IER Series LED display unit - for digital signage

Flexible design
Clearly refined visuals
Accurate color in low-brightness arena
Fine-tuned uniformity
Streamlined UHD content delivery
Manage content and devices anywhere

FREE Delivery on orders over €250

*** Note: There may be additional delivery charges For large monitors, we will contact you if this is the case. ***

1 Available to Ship
Order within 10Hrs 7Mins for: FREE Delivery (8 Jun or 9 Jun)

€1639.75 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

Samsung IE015R-F LED display delivers stunning picture quality at a cost-efficient price point. The display features easy installation and simple display management with ultimate flexibility in design.

Features Summary

Flexible design
The IER series' advanced design provides flexibility for any indoor retail or other business environment. With portrait and landscape orientation options, content can be displayed to meet the preferred layout for any store location.
Clearly refined visuals
LED HDR leverages advanced refinement technologies for true-to-life picture presentation. Dynamic Peaking and Inverse Tone Mapping enhance content to optimum peak brightness levels with improved contrast and without shine, and in-depth Color Mapping ensures an accurate expression of colors.
Accurate color in low-brightness arena
Conventional LED displays struggle to present red, green and blue color hues accurately in low grayscale settings. The IER series overcomes these challenges through a unique algorithm that maintains R/G/B gradation and delivers precise, detail-rich hues in low-brightness indoor environments.
Fine-tuned uniformity
Rigorous factory calibration and real-time DSLR camera sub-pixel calibration fine-tune all sub-pixels for uniform brightness and color chromaticity. When coupled with the Samsung LED Signage Manager's advanced picture settings, this enhanced treatment produces an excellent presentation.
Streamlined UHD content delivery
Samsung's compatible S-Box condenses the delivery of compelling content to a single, centralized device. The S-Box transmits UHD content across multiple IER series displays without requiring external boxes or splitters, helping businesses enjoy faster and more cost-efficient operations.
Manage content and devices anywhere
Compatibility with the MagicINFO platform enables IER series users to create, schedule and deploy content across an entire signage network. Users likewise can monitor and adjust display settings and troubleshoot potential performance issues from any location via remote access.

Specification Summary

Product Description

Samsung IE015R-F IER Series LED display unit - for digital signage

Product Type

LED display unit

Commercial Use

Yes - digital signage

HDR Technology

LED HDR

Frame Rate & Enhancement Technology

3840 Hz Refresh Rate

TV Tuner

No tuner

Picture Enhancements

Colour temperature adjustment, Dynamic Peaking Technology, Inverse Tone Mapping, Colour Mapping

Video Wall Display Unit

23.26" - SMD - 160 x 360 - 0.13 m²

Voltage

AC 120/230 V (50/60 Hz)

Dimensions (WxDxH) - panel

24 cm x 8.1 cm x 54 cm

Weight

3.2 kg

Specifications

General

Product Type

LED display unit

Commercial Use

Yes - digital signage

Series

IER Series

HDR Capable

Yes

HDR Technology

LED HDR

TV Tuner

No tuner

TV Tuner Presence

Modes

Portrait mode, landscape mode

Picture Enhancements

Colour temperature adjustment, Dynamic Peaking Technology, Inverse Tone Mapping, Colour Mapping

Design

Flexible design

Dimensions

Panel

Width

24 cm

Depth

8.1 cm

Height

54 cm

Weight

3.2 kg

Display

Frame Rate & Enhancement Technology

3840 Hz Refresh Rate

Colour Temperature

2800 - 10000K

Image Contrast Ratio

3000:1

Brightness

500 cd/m²

Viewing Angle

160 degrees

Viewing Angle (Vertical)

160 degrees

Features

MagicInfo, 16-bit support

Video Wall Display Unit

Pixel Pitch

1.5 mm

Pixel Configuration

1 red, 1 green, 1 blue

LED Type

SMD

Resolution

160 x 360

Area

0.13 m²

LED Lifetime

100000 hours

Maintenance

Front

Cabinet Diagonal Size

23.26"

Miscellaneous

Compliant Standards

UL, CB, FCC, RoHS, KCC, EMC Class A, IP20

Power

Power Device

Power supply

Input Voltage

AC 120/230 V (50/60 Hz)

Video Wall Display Unit Power Consumption (Max)

77 W

Video Wall Display Unit Power Consumption (Typical)

26 W

Video Wall Power Consumption (Max)

594 W/m²

Video Wall Power Consumption (Typical)

198 W/m²

Dimensions & Weight (Shipping)

Width (Shipping)

65.3 cm

Depth (Shipping)

14.8 cm

Height (Shipping)

35.4 cm

Weight (Shipping)

4.9 kg

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

10 - 80%
