HPE FlexNetwork 5140 48G PoE+ 4SFP+ EI - switch -

Images Manuals

Images for illustrative purposes

HPE FlexNetwork 5140 48G PoE+ 4SFP+ EI

Name: HPE FlexNetwork 5140 48G PoE+ 4SFP+ EI
Brand: HPE
SKU: WCEJL824A
Price: 7446.30 EUR
Availability: InStock

View all HPE Network Switches - Visit the HPE Store (JL824A) - (WCEJL824A)

Model: HPE FlexNetwork

FlexNetwork 5140 48G PoE+ 4SFP+ EI - switch - 52 ports - smart - rack-mountable

Scalability and High Availability
Comprehensive Security Control
Simplified Management
Enhanced Quality of Service

FREE Delivery on orders over €250

2 Available to Ship
Order within 5Hrs 44Mins for: FREE Delivery (8 Jun or 9 Jun)

€7446.30 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The HPE Networking Comware Switch Series 5140 EI delivers scalability, high availability, and low TCO at the access layer of medium and large enterprise campus networks. The series offers enterprise-class QoS and security, HPE Intelligent Resilient Fabric (IRF) stacking, static layer 3 routing and RIP; convenient fixed 10GbE uplink ports, PoE+, ACLs, and IPv6; and delivers energy savings with Energy Efficient Ethernet. The HPE Networking Comware Switch Series 5140 EI also includes Smart Management Center (SmartMC), an embedded network management tool that can be leveraged at no additional cost by small and medium networks for centralized management and operations. The series can also be managed with HPE Aruba Networking IMC for a single view of your entire network.

Specification Summary

Product Description

HPE FlexNetwork 5140 48G PoE+ 4SFP+ EI - switch - 52 ports - smart - rack-mountable

Device Type

Switch - 52 ports - L3 - smart

Enclosure Type

Rack-mountable 1U

Subtype

Gigabit Ethernet

Ports

48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+

Power Over Ethernet (PoE)

PoE+

PoE Budget

370 W

Performance

Latency (1000 Mbps): 5 µs ¦ Latency (10 Gbps): 3 µs ¦ Throughput: 132 Mpps ¦ Routing/switching capacity: 176 Gbps

Capacity

IPv4 routing table entries: 512 ¦ IPv6 routing table entries: 256 ¦ VLAN IDs: 4094

MAC Address Table Size

16384 entries

Jumbo Frame Support

9216 bytes

Routing Protocol

OSPF, RIP-1, RIP-2, IGMP, OSPFv2, IGMPv3, OSPFv3, static IPv4 routing, static IPv6 routing, CIDR

Remote Management Protocol

SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTPS, TFTP, CLI, NTP, ICMP, RADIUS

Features

Flow control, BOOTP support, ARP support, load balancing, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DiffServ support, High Availability, half duplex mode, full duplex mode, sFlow, STP support, RSTP support, VRRP support, MSTP support, ACL support, QoS, CAR, DHCP server, MLD snooping, DLDP support, STP Root Guard, DHCP relay, LACP, Port Security, Energy Efficient Ethernet, dynamic ARP protection, DHCP protection, MVRP, SPQ, port isolation, GARP, OpenFlow support, IP source guard, ICMP IRDP, Link Aggregation, VLAN Double Tagging (Q-in-Q), LLDP-MED, Smart Link, Guest VLAN, Ethernet OAM, proxy ARP, WRR, IRF Technology, BPDU protection, UDP support, MRP

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, ANSI/TIA-1057, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX, IEEE 802.1r

Power

AC 100-240 V (50/60 Hz)

Dimensions (WxDxH)

44 cm x 36 cm x 4.36 cm

Weight

8 kg

Manufacturer Warranty

Limited lifetime warranty

Specifications

EAN / GTIN:

0190017497273

General

Device Type

Switch - 52 ports - L3 - smart

Enclosure Type

Rack-mountable 1U

Subtype

Gigabit Ethernet

Ports

48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+

Power Over Ethernet (PoE)

PoE+

PoE Budget

370 W

Performance

Latency (1000 Mbps): 5 µs ¦ Latency (10 Gbps): 3 µs ¦ Throughput: 132 Mpps ¦ Routing/switching capacity: 176 Gbps

Capacity

IPv4 routing table entries: 512 ¦ IPv6 routing table entries: 256 ¦ VLAN IDs: 4094

MAC Address Table Size

16384 entries

Jumbo Frame Support

9216 bytes

Routing Protocol

OSPF, RIP-1, RIP-2, IGMP, OSPFv2, IGMPv3, OSPFv3, static IPv4 routing, static IPv6 routing, CIDR

Remote Management Protocol

SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTPS, TFTP, CLI, NTP, ICMP, RADIUS

Encryption Algorithm

SSL

Authentication Method

RADIUS, TACACS+, Secure Shell v.2 (SSH2), HWTACACS

Features

Compliant Standards

RAM

512 MB SDRAM

Flash Memory

256 MB

Status Indicators

Port status, system

Expansion / Connectivity

Interfaces

48 x 1000Base-T RJ-45 PoE+ ¦ 4 x Gigabit / 10Gbit LAN SFP+ ¦ 1 x console RJ-45 management ¦ 1 x micro-USB 5 pin USB header management

Power

Power Device

Internal power supply

Power Provided

478 Watt

Voltage Required

AC 100-240 V (50/60 Hz)

Miscellaneous

Rack Mounting Kit

Included

Compliant Standards

Plug and Play, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, ICES-003 Class A, RoHS, UL 60950-1, IEC 60950-1, WEEE, EN 60825-1, FCC Part 15 B Class A, EN 60825-2, IPv6 Ready, EN 300 386, FDA 21 CFR, AS/NZS CISPR 32 Class A, YD/T993, IEC 62368-1, EN 55032, CAN/CSA-C22.2 No. 60950-1, VCCI-CISPR 32:2016 Class A, ETSI EN 300 386, EN 62368-1:2014/A11:2017, GB/T9254

Dimensions & Weight

Width

44 cm

Depth

36 cm

Height

4.36 cm

Weight

8 kg

Manufacturer Warranty

Service & Support

Limited warranty - lifetime

Environmental Parameters

Min Operating Temperature

-5 °C

Max Operating Temperature

45 °C

Humidity Range Operating

10 - 90% (non-condensing)

Min Storage Temperature

-40 °C

Max Storage Temperature

70 °C

Humidity Range Storage

5 - 95% (non-condensing)
