Device Type
Switch - 48 ports - L3 - Managed
Enclosure Type
Front to back airflow rack-mountable 1U
Subtype
100 Gigabit Ethernet
Ports
48 x 10/25 Gigabit SFP+ / SFP28 + 8 x 40/100 Gigabit QSFP+ / QSFP28
Performance
Switching capacity: 6.4 Tbps ¦ Throughput: 1.905 Mpps
Capacity
Virtual interfaces (VLANs) per port for 802.1q: 4096
Routing Protocol
OSPF, EGP, BGP-4, BGP, IGMPv2, IGMP, VRRP, PIM-SM, static IP routing, IGMPv3, GRE, OSPFv3, static IPv6 routing, ECMP, policy-based routing (PBR), MLD, MSTP, RSTP, STP
Remote Management Protocol
SNMP, RMON, SNMP 3, SNMP 2c, TFTP, SSH, CLI, SFTP, NTP
Encryption Algorithm
FIPS 140-2
Authentication Method
Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Features
Routing, DHCP support, VPN support, ARP support, VLAN support, IGMP snooping, port mirroring, manageable, IPv6 support, sFlow, STP support, RSTP support, MSTP support, ACL support, QoS, Jumbo Frames support, MLD snooping, UDLD, Rapid PVST+, IPv4 support, LACP, fan tray, redundant hot swappable fans, packet storm protection, SP, Loopback, VTEP support, PIM
Compliant Standards
IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1t, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3ba, IEEE 802.1AX
Interfaces
48 x 10/25Gbit LAN ¦ 8 x 100Gbit/40Gbit LAN
Power Device
Internal power supply - hot-plug
Power Redundancy Scheme
N+1
Voltage Required
AC 120/230 V (50/60 Hz)
Included Accessories
6 x fans
Compliant Standards
RoHS, WEEE
Service & Support
Limited warranty - 5 years
