Startech HPE J4859C Compatible SFP Module, 1000BAS

Images Manuals

Startech HPE J4859C Compatible SFP Module, 1000BASE-LX, 1GbE Single Mode (SMF)/Multi Mode MMF Fiber Optic Transceiver, LC Connector, 10km, 1310nm, DDM

Images for illustrative purposes

Startech HPE J4859C Compatible SFP Module, 1000BASE-LX, 1GbE Single Mode (SMF)/Multi Mode MMF Fiber Optic Transceiver, LC Connector, 10km, 1310nm, DDM

View all STARTECH.COM Repeaters | Tranceivers - Visit the STARTECH.COM Store (J4859CST) - (MMEV933705)

Startech HPE J4859C Compatible SFP Module, 1000BASE-LX, 1GbE Single Mode (SMF)/Multi Mode MMF Fiber Optic Transceiver, LC Connector, 10km, 1310nm, DDM, HPE 1400, 1700, 1820, Mini GBIC - Lifetime Warranty (J4859CST) - SFP

Efficient Connectivity
Flexible Operational Environment
Advanced Diagnostics
Long-Distance Performance
Robust Compliance Standards

FREE Delivery on orders over €250

8 Available to Ship
Order within 6Hrs 46Mins for: Delivery (8 Jun or 9 Jun)

RRP ~~€77.77~~

€58.84 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

1000 Mbps (1 Gbps) | Single & Multi Mode Fiber | LC | 10 km (6.2 mi) | Lifetime Warranty. The J4859CST is an HP J4859C compatible fiber transceiver module that has been designed, programmed and tested to work with HP brand switches and routers. It delivers dependable 1 GbE connectivity over fiber cable, for 1000BASE-LX compliant networks, with a maximum distance of up to 10 km (6.2 mi).

Technical Specifications:

Wavelength: 1310 nm

Maximum Data Transfer Rate: 1.25 Gbps

Type: Single Mode / Multi Mode Fiber

Connection Type: LC Connector

Maximum Transfer Distance: 10 km (6.2 mi)

MTBF: 3,092,408 hours

Power Consumption: Less than 1 Watt

Digital Diagnostics Monitoring (DDM): Yes

This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.

Features Summary

Efficient Connectivity
This SFP module supports wired connectivity technology, ensuring stable and robust communication across networks. With Ethernet 1000Base-LX cabling type, it is ideal for high-speed data transmission.
Flexible Operational Environment
With an operating temperature range of 0°C to 70°C and a humidity range of 30% to 75%, this module functions reliably in various conditions, making it a versatile choice for different setups.
Advanced Diagnostics
Featuring Digital Diagnostics Monitoring (DDM), this module allows users to monitor the performance and status of the networking connection in real-time, enabling proactive management and troubleshooting.
Long-Distance Performance
The module supports a maximum transfer distance of 10 km, ensuring effective communication over extended distances without compromising data integrity.
Robust Compliance Standards
The HPE J4859C Compatible SFP Module adheres to compliance standards such as UL, FCC, RoHS, and MSA, ensuring it meets quality and safety requirements for reliable networking solutions.

Specification Summary

Product Description

Device Type

SFP (mini-GBIC) transceiver module - LC

Form Factor

Plug-in module

Cabling Type

1000Base-LX

Data Transfer Rate

1.25 Gbps

Optical Wave Length

1310 nm

Data Link Protocol

1GbE

Max Transfer Distance

10 km

OEM Manufacturer Equivalent Part Number

HP J4859C

Dimensions (WxDxH)

1.3 cm x 5.7 cm x 1.4 cm

Manufacturer Warranty

Limited lifetime warranty

Designed For

HPE 1700, 1810, 1910, 20p 10/100/1000, 2610, 2810, 3500, 42XX, 6200, 93XX, EDGE Fabric Switch 81XX, Switch 1800-24, Switch 26XX, Switch 2900-24, Switch 2900-48, Switch 5406, Switch 8212, Switch vl 4-port, Switch XL 10/100/1000, V1400, vl 20; HPE Aruba 2530, 2930F 24, 2930F 48, 5406, Switch 5400zl 24

Specifications

EAN / GTIN:

0065030865296

General

Device Type

SFP (mini-GBIC) transceiver module

Form Factor

Plug-in module

Colour

Silver

Networking

Connectivity Technology

Wired

Cabling Type

1000Base-LX

Data Link Protocol

1GbE

Data Transfer Rate

1.25 Gbps

Optical Wave Length

1310 nm

Max Transfer Distance

10 km

Features

Full duplex capability, Digital Diagnostics Monitoring (DDM)

Compliant Standards

IEEE 802.3z

Expansion / Connectivity

Interfaces

1 x Ethernet 1000Base-LX - LC x 2

Miscellaneous

Compliant Standards

UL, FCC, RoHS, MSA

OEM Manufacturer Equivalent Part Number

HP J4859C

Dimensions & Weight

Width

1.3 cm

Depth

5.7 cm

Height

1.4 cm

Manufacturer Warranty

Service & Support

Limited warranty - lifetime

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

70 °C

Humidity Range Operating

30 - 75%

Compatibility Information

Designed For

HP 9400sl 40-Port Mini-GBIC Module, EP Redundant Management Module, Switch 2510-24, Switch 5406zl-48G Intelligent Edge, Switch 5412zl Intelligent Edge, Switch 5412zl-96G Intelligent Edge ¦ HPE 1700-24 Switch, 1810-24 v2, 1810-8 v2, 1910-8G Switch, 1910-8G-PoE+ (180W) Switch, 1910-8G-PoE+ (65W) Switch, 20p 10/100/1000 + 4p Mini-GBIC Module, 2610-24 Switch, 2610-24-PoE Switch, 2610-24-PPoE Switch, 2610-48 Switch, 2610-48-PoE Switch, 2810-24G Switch, 2810-48G Switch, 3500-24G-PoE yl Switch, 3500-48G-PoE yl Switch, 4202-72 vl Switch, 4204 vl Switch, 4204-44G-4SFP vl Switch, 4208 vl Switch, 4208-68G-4SFP vl Switch, 4208-96 vl Switch, 6200-24G-mGBIC yl Switch, 9304M, 9308M, 9315M, EDGE Fabric Switch 8108fl, EDGE Fabric Switch 8116fl, Switch 1800-24G, Switch 2600-8-PWR, Switch 2626, Switch 2626-PWR, Switch 2650, Switch 2650-PWR, Switch 2824, Switch 2848, Switch 2900-24G, Switch 2900-48G, Switch 3400cl-24G, Switch 3400cl-48G, Switch 4140gl, Switch 4160gl, Switch 5304XL-32G, Switch 5308xl, Switch 5308XL-48G, Switch 5348 XL-G, Switch 5348xl, Switch 5372xl, Switch 5406zl Intelligent Edge, Switch 6108, Switch 8212zl, Switch fl 10-Port Mini-GBIC Interface Module, Switch gl 10/100/1000 Module, Switch gl Mini-GBIC Module, Switch vl 4-port Mini-GBIC Module, Switch XL 10/100/1000 Module, Switch xl Mini-GBIC Module, V1400-24G Switch, vl 20p Gig-T+ 4P SFP module switch ¦ HPE Aruba 2530-24G, 2530-24G-PoE+, 2530-48G, 2530-48G-PoE+, 2530-48-PoE+, 2930F 24G 4SFP, 2930F 24G 4SFP+, 2930F 24G PoE+ 4SFP, 2930F 48G 4SFP, 2930F 48G 4SFP+, 2930F 48G PoE+ 4SFP, 2930F 48G PoE+ 4SFP+, 5406 zl, Switch 5400zl 24p Mini-GBIC Module
