HPE R/T3000 G4 Low Voltage - UPS - 2700 Watt - 288

Images Manuals

Images for illustrative purposes

HPE R/T3000 G4 Low Voltage

View all HPE Uninteruptable Power Supply - Visit the HPE Store (J2R01A) - (ECE3358635)

R/T3000 G4 LV NA/JP UPS

Ultra-Dense Rack UPS Models Scale from Small to Enterprise IT Environments

FREE Delivery on orders over €250

**Note: There may be an extra delivery charge on some very large UPS, we will notify you if this is the case. Please ensure you are buying the correct UPS or Battery, once a UPS or Battery is opened it cannot be returned. Please contact sales through email, chat or phone if you need to confirm.

0 Available to Ship
Restock 03-Jul-2026 Estimated, Out of Stock Prices are Estimated.

€1534.68 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

Looking for cost-effective power protection for light workload IT equipment? HPE Line Interactive Single Phase Uninterruptible Power Systems (UPS) range from tower-based systems designed to safeguard tower servers and small office equipment, to rack-based systems that protect a full rack of servers. Standard features include an intuitive front panel display for local management, hot-swappable battery modules, and optional HPE Enhanced Battery Management (EBM) modules that help to extend the service-life of your batteries. HPE Power Protection, a power management software application that ships with each model, combined with a UPS Network Module, optional on some models, enables you to remotely monitor and manage your UPS through HPE Systems Insight Manager or via a standard web browser. Backed by a 3-year limited warranty, HPE's exclusive 30-day Battery Pre-Failure Warning provides notification of an impending battery failure and free battery replacement while under the warranty.

Specification Summary

Product Description

HPE R/T3000 G4 Low Voltage - UPS - 2700 Watt - 2880 VA

Device Type

UPS - rack-mountable / external

Rack Size

Weight

39.54 kg

Localisation

Japan, North America

Input Voltage

AC 100/120-125 V

Power Capacity

2700 Watt / 2880 VA

Input Connectors

1 x power NEMA L5-30

Output connectors

6 x power NEMA 5-20 ¦ 1 x power NEMA L5-30

Battery

Lead Acid expandable

Batteries Qty

1 (installed) / 5 (supported)

Run Time (Up To)

4 min at full load

Networking

RS-232, USB

Included Accessories

Rack mounting rails, floor stand

Dimensions (WxDxH)

44.1 cm x 64.7 cm x 86.2 cm

Manufacturer Warranty

3-year warranty

Designed For

ProLiant DL120 Gen9, DL160 Gen9, DL180 Gen9, DL20 Gen9, DL320e Gen8, DL360e Gen8, DL360p Gen8, DL380 Gen9, DL380e Gen8, DL380p Gen8, DL385p Gen8, DL560 Gen8, DL580 Gen8, DL580 Gen9, DL60 Gen9, DL80 Gen9, MicroServer Gen8, ML10, ML10 v2, ML110 Gen9, ML150 Gen9, ML310e Gen8, ML350e Gen8, ML350p Gen8

Specifications

EAN / GTIN:

4514953741447

General

Device Type

UPS - rack-mountable / external

Height (Rack Units)

Localisation

Japan, North America

Power Device

Input Voltage

AC 100/120-125 V

Frequency Required

50/60 Hz

Input Connectors

1 x power NEMA L5-30

Power Output Connectors Details

6 x power NEMA 5-20 ¦ 1 x power NEMA L5-30

Power Capacity

2700 Watt / 2880 VA

Output Waveform

Sinewave

Circuit Protection

Circuit breaker

Efficiency

94%

Battery

Type

Expandable

Quantity

1 (installed) / 5 (supported)

Technology

Lead Acid

Voltage Provided

12 V

Run Time (Up To)

40 min at 20% load ¦ 12 min at half load ¦ 6 min at 80% load ¦ 4 min at full load

Recharge Time

48 hours

Features

Maintenance free, sealed

Networking

Remote Management Interface

RS-232, USB

Expansion / Connectivity

Interfaces

1 x USB ¦ 1 x RS-232 - 9 pin D-Sub (DB-9)

Expansion Slots

1 (total) / 1 (free) x Expansion Slot

Miscellaneous

Included Accessories

Rack mounting rails, floor stand

Cables Included

USB cable ¦ Serial cable ¦ Power cable - integrated - 2.4 m

Rack Mounting Kit

Included

Equipment Protection Value

250000 US Dollars

Features

LCD display, Remote Emergency Power Off (REPO)

Compliant Standards

UL, VCCI, cUL, EN 60950, UL 1778, IEC 62040-1-1, UL 60950-1, IEC 60950-1, WEEE, CSA C22.2 No. 107.3, EN 62040-1

Software / System Requirements

Software Included

HP Power Protector (free download)

Manufacturer Warranty

Service & Support

Limited warranty - parts and labour - 1 year ¦ Limited warranty - 3 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

20 - 90% (non-condensing)

Dimensions & Weight

Width

44.1 cm

Depth

64.7 cm

Height

86.2 cm

Weight

39.54 kg

Dimensions & Weight (Shipping)

Shipping Width

59 cm

Shipping Depth

92.1 cm

Shipping Height

28 cm

Shipping Weight

48.75 kg

Compatibility Information

Designed For

HPE ProLiant DL120 Gen9, DL120 Gen9 Entry, DL160 Gen8, DL160 Gen8 Base, DL160 Gen8 Performance, DL160 Gen9, DL160 Gen9 Base, DL160 Gen9 Entry, DL160 Gen9 Performance, DL180 Gen9, DL180 Gen9 Base, DL180 Gen9 Entry, DL180 Gen9 Storage, DL20 Gen9, DL20 Gen9 Entry, DL20 Gen9 Performance, DL320e Gen8, DL320e Gen8 Base, DL320e Gen8 Entry, DL320e Gen8 Performance, DL320e Gen8 Special Server, DL320e Gen8 v2, DL320e Gen8 v2 Base, DL320e Gen8 v2 Entry, DL320e Gen8 v2 Performance, DL360e Gen8, DL360e Gen8 Base, DL360e Gen8 Entry, DL360e Gen8 Performance, DL360e Gen8 Special Server, DL360p Gen8, DL360p Gen8 Performance, DL380 Gen9, DL380 Gen9 Base, DL380 Gen9 Entry, DL380 Gen9 High Performance, DL380 Gen9 Performance, DL380e Gen8, DL380e Gen8 Base, DL380e Gen8 Entry, DL380e Gen8 High Performance, DL380e Gen8 Storage, DL380p Gen8 Performance, DL380p Gen8 Special, DL385p Gen8, DL385p Gen8 Dedicated Workload, DL385p Gen8 Entry, DL385p Gen8 Maximized Consolidation, DL385p Gen8 Storage, DL385p Gen8 Storage Centric, DL560 Gen8, DL560 Gen8 Base, DL560 Gen8 Entry, DL560 Gen8 Performance, DL580 Gen8, DL580 Gen8 Base, DL580 Gen8 High Performance, DL580 Gen9, DL580 Gen9 Base, DL580 Gen9 High Performance, DL580 Gen9 SAP HANA Scale-out Base Configuration, DL580 Gen9 SAP HANA Scale-up Base Configuration, DL60 Gen9, DL60 Gen9 Base, DL60 Gen9 Entry, DL80 Gen9, DL80 Gen9 Base, DL80 Gen9 Entry, MicroServer Gen8, MicroServer Gen8 Base, MicroServer Gen8 Entry, MicroServer Gen8 Performance, ML10, ML10 Entry, ML10 Special, ML10 v2, ML10 v2 Base, ML10 v2 Entry, ML10 v2 Performance, ML110 Gen9, ML110 Gen9 Base, ML110 Gen9 Entry, ML150 Gen9, ML150 Gen9 Base, ML150 Gen9 Entry, ML150 Gen9 Performance, ML310e Gen8, ML310e Gen8 v2, ML310e Gen8 v2 Base, ML310e Gen8 v2 Enty, ML310e Gen8 v2 Performance, ML350e Gen8, ML350e Gen8 Base, ML350e Gen8 Entry, ML350e Gen8 v2, ML350e Gen8 v2 Base, ML350e Gen8 v2 Entry, ML350p Gen8, ML350p Gen8 Special Server
