ViewSonic ViewBoard IFP7562 75" Class (74.5" viewable) LED-backlit LCD display

Images for illustrative purposes

ViewSonic ViewBoard IFP7562 75" Class (74.5" viewable) LED-backlit LCD display

Name: ViewSonic ViewBoard IFP7562 75" Class (74.5" viewable) LED-backlit LCD display
Brand: VIEWSONIC
SKU: MMECE93494
Price: 4649.74 EUR
Availability: InStock

View all VIEWSONIC Digital Signage | Large Displays - Visit the VIEWSONIC Store (IFP7562) - (MMECE93494)

Model: ViewSonic ViewBoard

ViewBoard IFP7562 75" Class (74.5" viewable) LED-backlit LCD display - 4K - for interactive communication

High-performance 4K touchscreen
Sleek and slim design
Convenient USB Type-C
Built-in microphone array

FREE Delivery on orders over €250

2 Available to Ship
Order within 16Hrs 43Mins for: FREE Delivery (8 Jun or 9 Jun)

€4649.74 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

From executive boardrooms to kindergarten classrooms, the ViewSonic ViewBoard IFP7562 enables limitless collaboration and endless innovation. Designed to help teams connect, collaborate, and create, this next-generation digital whiteboard delivers exactly what you need to move your ideas forward. A premium, state-of-the-art design features a bezel-less PCAP (projected capacitive) touchscreen with incredible 4K Ultra HD resolution. This highly accurate interactive screen provides for an incredibly natural and responsive handwriting experience. Using fingers, styluses, or both, multiple users can simultaneously write or draw on the huge 75" ViewBoard panel. What's more, meetings and presentations start fast thanks to convenient one-wire USB-C connectivity.

Features Summary

High-performance 4K touchscreen
Perfect for heavy usage in meeting rooms or classrooms, this display features an anti-glare and tempered glass screen for enhanced durability and clarity. 20-point PCAP (projected capacitive) touch technology delivers an ultra-smooth and natural handwriting experience, while 4K Ultra HD resolution provides incredibly vivid and lifelike images.
Sleek and slim design
Sleek, slim, and less than an inch thick, this premium LCD display looks as good as it performs. An edge-to-edge glass screen and bezel-less design enhance interactivity and viewing.
Convenient USB Type-C
Meetings and presentations start fast with single cable USB Type-C connectivity. Users can simply walk into a room, plug in their device, and immediately begin sharing info on the ViewBoard display. In addition to fast data, audio, and video transfer, USB Type-C also provides quick 65 W charging and touch pass-through over a single cable.
Built-in microphone array
An integrated microphone array with echo cancellation and noise reduction technology delivers clear speech and sound during video conferences. The microphone can also pick up sound from up to 26 feet away.

Specification Summary

Product Description

ViewSonic ViewBoard IFP7562 75" Class (74.5" viewable) LED-backlit LCD display - 4K - for interactive communication

Product Type

LED-backlit LCD flat panel display

Diagonal Class

75"

Diagonal Size

74.5"

Commercial Use

Yes - interactive

Resolution

3840 x 2160

Display Format

4K UHD (2160p)

Video Interface

HDMI

HDMI Ports Qty

4 ports

Connectivity

LAN

PC Interface

HDMI, USB, serial RS-232, USB 3.0, USB-C 3.1

LCD Backlight Technology

LED backlight

Image Aspect Ratio

16:9

TV Tuner

No tuner

Speaker System

2 speakers, subwoofer

Storage Capacity

32 GB

USB

Yes

Included Accessories

Remote control, 2 styluses, 8 screws, camera plate, 5 clamps, RS232 adapter

Power Consumption Operational

130 Watt

Power Consumption Stand by

0.5 Watt

Dimensions (WxDxH)

171.2 cm x 7.8 cm x 103.1 cm

Weight

50.1 kg

Environmental Standards

ENERGY STAR Qualified

Manufacturer Warranty

3-year warranty

Specifications

EAN / GTIN:

0766907012071

General

Product Type

LED-backlit LCD flat panel display

Power Consumption (Max)

490 Watt

Power Consumption Operational

130 Watt

Diagonal Class

75"

Diagonal Size

74.5"

Commercial Use

Yes - interactive

Operating System

Android OS 8.0

TV Tuner

No tuner

TV Tuner Presence

Video Interface

HDMI

HDMI Ports Qty

4 ports

PC Interface

HDMI, USB, serial RS-232, USB 3.0, USB-C 3.1

Width

171.2 cm

Depth

7.8 cm

Height

103.1 cm

Weight

50.1 kg

Display

Resolution

3840 x 2160

Display Format

4K UHD (2160p)

Image Aspect Ratio

16:9

LCD Backlight Technology

LED backlight

Coating

Anti-glare, 9H Hard

Image Contrast Ratio

5000:1

Brightness

350 cd/m²

Viewing Angle

178 degrees

Viewing Angle (Vertical)

178 degrees

Touchpoints Qty

Response Time

8 ms

Backlight Life

30,000 hours

Features

Projected Capacitive Technology (PCAP)

Stands & Mounts

Flat Panel Mount Interface

800 x 400 mm

VESA Compatibility

Yes

Media Player

USB Port

Yes

Configuration

ARM Cortex-A73 Quad-Core ( 1.2 GHz ) - 3 GB - 32 GB

Remote Control

Type

Remote control

Battery Included

Yes

Audio System

Speaker System

2 speakers, subwoofer

Output Power / Total

29 Watt

Speakers

2 x main channel speaker - 12 Watt ¦ 1 x subwoofer - 15 Watt

Network & Internet Multimedia

Connectivity

LAN

LAN Protocol

Fast Ethernet

Connections

Connector Type

4 x HDMI input ¦ HDMI output ¦ USB-C 3.1 ¦ Audio output ¦ 5 x USB 3.0 ¦ USB 2.0 ¦ USB 2.0 ¦ Gigabit LAN ¦ LAN ¦ SPDIF output

Miscellaneous

Included Accessories

2 styluses, 8 screws, camera plate, 5 clamps, RS232 adapter

Cables Included

USB cable ¦ HDMI cable ¦ USB-C cable

Compliant Standards

CB, FCC, cTUVus, REACH, ERP, Mexico Energy label, UKCA

Sustainability Information

ENERGY STAR Certified

Yes

ENERGY STAR Version

8.0

Power

Power Device

Power supply

Power Consumption Stand by

0.5 Watt

Manufacturer Warranty

Service & Support

Limited warranty - parts and labour - 3 years - on-site ¦ Limited warranty - backlight - 3 years - on-site

Dimensions & Weight (Shipping)

Width (Shipping)

184.8 cm

Depth (Shipping)

27 cm

Height (Shipping)

112.1 cm

Weight (Shipping)

66.3 kg

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

10 - 90% (non-condensing)
