Range/Series Overview
IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.Connect up to 8 different GbE (4 PoE+) devices, using this IP30 industrial Ethernet switch with intelligent Layer 2 management. Easily deploy or scale your network with this Gigabit Ethernet switch, by adding eight copper Gigabit Ethernet (GbE) connections, including four PoE+ ports. This IP30 industrial network switch provides intelligent Layer 2 management. Its rugged, compact design and wall-mount option with front access make it ideal for demanding applications, even where space is limited.
This Gigabit Ethernet switch lets you expand your network by connecting up to eight RJ45 devices (four PoE+). The 8-port switch enables up to eight users to share files and devices, such as printers and scanners, over a LAN connection, by enhancing your existing network capacity with additional ports.
The switch gives you the freedom to place your equipment in locations where power outlets are not available, with support for Power over Ethernet Plus. The network switch provides abundant PoE power, with up to 30 watts for each PoE port (120W budget).
With its compact design, you can wall-mount the Gigabit switch to provide convenient front access to ports and indicators. It's ideal for a wide range of applications, including tight installation areas with significant electromagnetic interference, such as control cabinets and panels. The network switch is also DIN-rail mountable.
The switch delivers efficient and stable performance, with Layer 2 management capabilities. This lets you control packet traffic on a busy network, and customize your settings to achieve optimal network performance, offering improved efficiency and reliability.
This rugged network switch features an IP30-rated metal housing and extended operating temperature range of -40°C to 75°C, which makes it ideal for a wide range of conditions. The sturdy metal enclosure offers durability, even in harsh industrial environments.
With support for 10/100/1000Mbps transfer speeds, this managed switch supports full/half-duplex auto-negotiation, jumbo frames, and auto MDI/MDIX operation. This lets you connect your network devices quickly and easily, with little to no configuration required.
To help prevent any unnecessary downtime, the switch features redundant 12-58V DC terminal block power inputs, which ensures seamless operation in the event of power dips or failures.
Features Summary
- Robust performance
With a data transfer rate of 2 Gbps, this switch ensures smooth and fast connectivity across multiple devices, enhancing overall network efficiency. - Extensive compatibility
Supports a wide range of networking standards, including IEEE 802.3 and IEEE 802.1, allowing for seamless integration into existing networks. - Durable construction
Designed for resilience, the switch has a minimal MTBF of over 100,000 hours, ensuring a longer lifespan and reduced maintenance needs. - Flexible power options
Features PoE+ technology, providing 30 W of power to connected devices, which minimizes cable clutter and simplifies network deployment. - User-friendly management
Includes remote management capabilities via HTTP, making it easier to monitor and configure settings remotely.
Specification Summary
Product Description
Startech Industrial 8 Port Gigabit PoE Switch, 4 x PoE+ 30W, Power Over Ethernet, Hardened GbE Layer/L2 Managed Switch, Rugged High Power Gigabit Network Switch IP-30/-40C to +75C - Managed Network Switch (IES81GPOEW) - switch - 8 ports - Managed
Device Type
Switch - 8 ports - Managed
Ports
4 x 10/100/1000 + 4 x 10/100/1000 (PoE+)
Power Over Ethernet (PoE)
PoE+
Performance
Data transfer rate: 2 Gbps
Capacity
Buffer capacity (MB): 0.512
Routing Protocol
IGMP, MLD
Remote Management Protocol
HTTP
Features
Layer 2 switching, IPv6 support, full duplex mode, wall mountable, TFTP support, tagged VLAN, 6KV ESD Protector, 802.1x authentication, ICMP, 6KV EFT protector
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at
Dimensions (WxDxH)
14.8 cm x 13.4 cm x 2.5 cm
Manufacturer Warranty
2-year warranty
