Startech Industrial 8 Port Gigabit PoE+ Switch wit

Images Manuals

Startech Industrial 8 Port Gigabit PoE+ Switch with 2 SFP MSA Slots, 30W, Layer/L2 Switch Hardened GbE Managed, Rugged High Power Gigabit Ethernet Net

Images for illustrative purposes

Startech Industrial 8 Port Gigabit PoE+ Switch with 2 SFP MSA Slots, 30W, Layer/L2 Switch Hardened GbE Managed, Rugged High Power Gigabit Ethernet Net

Name: Startech Industrial 8 Port Gigabit PoE+ Switch with 2 SFP MSA Slots, 30W, Layer/L2 Switch Hardened GbE Managed, Rugged High Power Gigabit Ethernet Net
Brand: STARTECH.COM
SKU: MMEV934033
Price: 492.62 EUR
Availability: InStock

View all STARTECH.COM Network Switches - Visit the STARTECH.COM Store (IES101GP2SFW) - (MMEV934033)

Model: Startech

Startech Industrial 8 Port Gigabit PoE+ Switch with 2 SFP MSA Slots, 30W, Layer/L2 Switch Hardened GbE Managed, Rugged High Power Gigabit Ethernet Network Switch IP-30/-40 C to 75 C - Managed Network Switch (IES101GP2SFW) - switch - 10 ports - Managed

Expand your network
Supports PoE+ for flexible use
Wall-mountable with front access
Efficient Layer 2 management
Rugged IP30 industrial design

FREE Delivery on orders over €250

2 Available to Ship
Order within 17Hrs 9Mins for: FREE Delivery (8 Jun or 9 Jun)

RRP ~~€531.69~~

€492.62 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

Easily deploy or scale your network with this Gigabit Ethernet switch, by adding eight copper Gigabit Ethernet ports (PoE+) and two fiber-optic SFP slots. This IP30 industrial network switch provides intelligent Layer 2 management. Its rugged, compact design and wall-mount option with front access make it ideal for demanding applications, even where space is limited. Expand your network This versatile switch adapts to your network needs by providing two open SFP slots and eight RJ45 Ethernet ports (PoE+), providing both fiber and copper connections in a single network device. The MSA compliant SFP ports are compatible with 100/1000Mbps networks. The network switch enables you to connect up to eight RJ45 PoE+ devices, so different users can share files and devices, such as printers and scanners, over a LAN connection. Supports PoE+ for flexible use Dual power input (terminal block and DC plug) provides flexible power options. The switch gives you the freedom to place your equipment in locations where power outlets are not available, with support for Power over Ethernet Plus. The network switch provides abundant PoE power, with up to 30 watts for each PoE port (200W budget). Wall-mountable with front access Wall-mount the compact Gigabit switch to provide convenient front access to ports and indicators. It's ideal for a wide range of applications, including tight installation areas with significant electromagnetic interference, such as control cabinets and panels. The network switch is also DIN-rail mountable. Efficient Layer 2 management The switch delivers efficient and stable performance, with Layer 2 management capabilities. This lets you control packet traffic on a busy network, and customize your settings to achieve optimal network performance, offering improved efficiency and reliability. Rugged IP30 industrial design This rugged network switch features an IP30-rated metal housing and extended temperature range of -40°C to 75°C, which makes it ideal for a wide range of operating conditions. The sturdy metal enclosure offers durability, even in harsh industrial environments. Reliable connection for seamless network performance With support for 10/100/1000Mbps transfer speeds, this managed switch supports full/half-duplex auto-negotiation, jumbo frames and auto MDI/MDIX operation. This lets you connect your network devices quickly and easily, with little to no configuration required. The IES101GP2SFW is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Features Summary

Expand your network
This versatile switch adapts to your network needs by providing two open SFP slots and eight RJ45 Ethernet ports (PoE+), providing both fiber and copper connections in a single network device. The MSA compliant SFP ports are compatible with 100/1000Mbps networks. The network switch enables you to connect up to eight RJ45 PoE+ devices, so different users can share files and devices, such as printers and scanners, over a LAN connection.
Supports PoE+ for flexible use
Dual power input (terminal block and DC plug) provides flexible power options. The switch gives you the freedom to place your equipment in locations where power outlets are not available, with support for Power over Ethernet Plus. The network switch provides abundant PoE power, with up to 30 watts for each PoE port (200W budget).
Wall-mountable with front access
Wall-mount the compact Gigabit switch to provide convenient front access to ports and indicators. It's ideal for a wide range of applications, including tight installation areas with significant electromagnetic interference, such as control cabinets and panels. The network switch is also DIN-rail mountable.
Efficient Layer 2 management
The switch delivers efficient and stable performance, with Layer 2 management capabilities. This lets you control packet traffic on a busy network, and customize your settings to achieve optimal network performance, offering improved efficiency and reliability.
Rugged IP30 industrial design
This rugged network switch features an IP30-rated metal housing and extended temperature range of -40°C to 75°C, which makes it ideal for a wide range of operating conditions. The sturdy metal enclosure offers durability, even in harsh industrial environments.

Specification Summary

Product Description

Device Type

Switch - 10 ports - Managed

Subtype

Gigabit Ethernet

Ports

8 x 10/100/1000 (PoE+) + 2 x SFP

Power Over Ethernet (PoE)

PoE+

PoE Budget

200 W

Performance

Data transfer rate: 2 Gbps

Jumbo Frame Support

9KB

Routing Protocol

IGMP, MLD

Remote Management Protocol

HTTP

Features

Flow control, Layer 2 switching, IPv6 support, full duplex mode, wall mountable, TFTP support, tagged VLAN, 6KV ESD Protector, 802.1x authentication, ICMP, 6KV EFT protector

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at

Dimensions (WxDxH)

14.8 cm x 13.4 cm x 2.5 cm

Weight

496 g

Colour

Black

Manufacturer Warranty

2-year warranty

Designed For

P/N: 3CSFP91ST, 453154B21ST, EXSFP1GELXST, EXSFP1GESXST, EXSFP1GETST, GLCEXSMDST, GLCLHSMDSTTA, GLCLXSMRGDST, GLCSXMMDST, GLCSXMMDSTT, GLCSXMMRGDST, GLCTEST, GLCTSTTAA, GLCZXSMRGDST, J4859CST, J8177C10PKST, J8177CST, JD089BST, JD118BST, JD119BST, MASFP1GBLX10, MASFP1GBSXST, MASFP1GBTXST, SFP1GELXST

Specifications

EAN / GTIN:

0065030871198

General

Device Type

Switch - 10 ports - Managed

Enclosure Type

DIN rail mountable, wall-mountable

Subtype

Gigabit Ethernet

Ports

8 x 10/100/1000 (PoE+) + 2 x SFP

Power Over Ethernet (PoE)

PoE+

PoE Budget

200 W

Performance

Data transfer rate: 2 Gbps

Jumbo Frame Support

9KB

Routing Protocol

IGMP, MLD

Remote Management Protocol

HTTP

Features

Flow control, Layer 2 switching, IPv6 support, full duplex mode, wall mountable, TFTP support, tagged VLAN, 6KV ESD Protector, 802.1x authentication, ICMP, 6KV EFT protector

Compliant Standards

Status Indicators

Power

Expansion / Connectivity

Interfaces

8 x 1000Base-TX RJ-45 PoE+ - 30 W ¦ 2 x 1000Base-TX SFP ¦ 1 x terminal block

Miscellaneous

Colour

Black

Included Accessories

4 magnets, DIN-rail mounting kit, 4 x screws, 2 SFP dust caps, attaching pins, locking pins, 4 washers, 8 RJ45 dust caps

MTBF

>100,000 hours

Compliant Standards

FCC, RoHS, WEEE, IP30, RCM

Dimensions & Weight

Width

14.8 cm

Depth

13.4 cm

Height

2.5 cm

Weight

496 g

Manufacturer Warranty

Service & Support

Limited warranty - 2 years

Environmental Parameters

Min Operating Temperature

-40 °C

Max Operating Temperature

75 °C

Humidity Range Operating

5 - 95% (non-condensing)

Compatibility Information

Designed For

P/N: 3CSFP91ST, 453154B21ST, EXSFP1GELXST, EXSFP1GESXST, EXSFP1GETST, GLCEXSMDST, GLCLHSM10PST, GLCLHSMD10ST, GLCLHSMDST, GLCLHSMDSTTA, GLCLXSMRGDST, GLCSXMM10PST, GLCSXMMDST, GLCSXMMDSTT, GLCSXMMRGDST, GLCT10PKST, GLCTEST, GLCTST, GLCTSTTAA, GLCZXSMRGDST, J4858C10PKST, J4858CST, J4859C10PKST, J4859CST, J8177C10PKST, J8177CST, JD089BST, JD118BST, JD119BST, MASFP1GBLX10, MASFP1GBSXST, MASFP1GBTXST, SFP1GELXST, SFPC1110, SFPG1320C, SFPGESST, SFPGLCLHSMST, SFPGLCSXMMST, SFPSXMM
