Cisco Industrial Ethernet 2000 IP67 Series - switc

Images Manuals

Cisco Industrial Ethernet 2000 IP67 Series

Images for illustrative purposes

Cisco Industrial Ethernet 2000 IP67 Series

Name: Cisco Industrial Ethernet 2000 IP67 Series
Brand: CISCO
SKU: ECE5486181
Price: 3524.39 EUR
Availability: OutOfStock

View all CISCO Network Switches - Visit the CISCO Store (IE-2000-16T67-B) - (ECE5486181)

Model: Cisco Industrial

Industrial Ethernet 2000 IP67 Series - Switch - Managed - 16 x 10/100 - wall-mountable

Certified IP67 rating
Compliant with industrial automation standards
Easy deployment
Resiliency
Manageability
Network address translation (NAT)
View More
Industrial power-over-Ethernet (PoE)
Removable SD Flash memory

FREE Delivery on orders over €250

0 Available to Ship
Restock 03-Jul-2026 Estimated, Out of Stock Prices are Estimated.

RRP ~~€4824.05~~

€3524.39 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The Cisco Industrial Ethernet (IE) 2000 IP67 Series is Cisco's first ruggedized switching platform that complies with the most demanding IP67 industrial standards. It also provides everything you've come to expect from the global leader in Internet Protocol (IP) networking: easy integration with the rest of your network, reliability, rock‑solid performance, and world-class support. Now, those advantages and Cisco IOS Software features extend all the way to the factory floor, rail yard, or other industrial site, even in the harshest environments. So you can finally fulfill the promise of network convergence-across both information technology (IT) and operations technology (OT) environments-with one supplier.

Features Summary

Certified IP67 rating
The solution is IP67-rated to protect against dust and submersion in water. It meets the most rigorous industrial and safety standards for extreme temperature and vibration, humidity, electromagnetic emissions, and other factors.
Compliant with industrial automation standards
The rugged switch supports Common Industrial Protocol (CIP) and the PROFINET v2 standard, so you can easily integrate it with any Ethernet-based industrial equipment and management system. It also supports Precision Timing Protocol (PTP) v2 for demanding synchronized applications.
Easy deployment
With zero-touch discovery using Dynamic Host Control Protocol (DHCP), express setup, and sub-60-second boot-up times, you can easily migrate to all-IP-over-Ethernet networking environment.
Resiliency
Cisco brings recovery mechanisms such as flex links and Cisco Resilient Ethernet Protocol (REP) to the factory floor or other industrial site.
Manageability
The solution is easy for operations staff to configure and manage. Cisco Auto Smart Port lets you configure the right quality of service (QoS) settings for any port in seconds. It also allows for secure web-based administration and easy integration with your network management system.
Network address translation (NAT)
The switches provide line-rate, hardware-enabled static address translation to easily connect complex Layer‑2/machine node networks.
Industrial power-over-Ethernet (PoE)
Select switch models let you connect and power endpoints with a single cable in compliance with PoE and PoE+ standards.
Removable SD Flash memory
With tightly secured swappable hard drives, you can quickly replace switches in the field with minimal disruption.

Specification Summary

Product Description

Cisco Industrial Ethernet 2000 IP67 Series - switch - 16 ports - Managed

Device Type

Switch - 16 ports - Managed

Subtype

Fast Ethernet

Ports

16 x 10/100

Performance

Forwarding performance (64-byte packet size): 6.5 Mpps

Capacity

IGMP groups: 255 ¦ VLANs supported: 1005

MAC Address Table Size

8K entries

Routing Protocol

OSPF, RIP, BGP, static IPv4 routing, static IPv6 routing

Remote Management Protocol

SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SSH

Features

BOOTP support, ARP support, Cisco Fast EtherChannel, VLAN support, IGMP snooping, Syslog support, DiffServ support, MAC address filtering, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, STP support, RSTP support, MSTP support, DHCP snooping, TFTP support, QoS, DHCP server, DAI, UDLD, LLDP support, DHCP relay, Port Security, MAC Address Notification, RSPAN, CoS, IGMP filtering, PROFINET v2

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP)

Dimensions (WxDxH)

30.07 cm x 8.15 cm x 24.17 cm

Weight

3.3 kg

Manufacturer Warranty

5-year warranty

Specifications

EAN / GTIN:

0882658623592

General

Device Type

Switch - 16 ports - Managed

Enclosure Type

Wall-mountable

Subtype

Fast Ethernet

Ports

16 x 10/100

Performance

Forwarding performance (64-byte packet size): 6.5 Mpps

Capacity

IGMP groups: 255 ¦ VLANs supported: 1005

MAC Address Table Size

8K entries

Routing Protocol

OSPF, RIP, BGP, static IPv4 routing, static IPv6 routing

Remote Management Protocol

SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SSH

Authentication Method

Secure Shell (SSH), RADIUS, TACACS+

Features

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP)

RAM

256 MB

Flash Memory

64 MB

Expansion / Connectivity

Interfaces

16 x 100Base-TX M12 ¦ 1 x console M12

Expansion Slots

1 (total) / 1 (free) x SD Memory Card

Power

Power Consumption Operational

10 Watt

Miscellaneous

MTBF

374,052 hours

Compliant Standards

CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN55024, EN55022 Class A, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-6-2, EN 61000-4-8, NEMA Type 4, UL 60950-1, IEC 60950-1, EN 60950-1, EN 61000-6-4, IEC 60068-2-30, IEC 60068-2-27, IEC 60068-2-32, IEC 60068-2-6, UL 508, EN 55011, IP67, CSA 22.2 No. 142, EN 61131-2, IEC 60068-2-64, EN 61000-4-9, EN 61000-4-29, EN50155, IEC 60068-2-14, IEC 60068-2-31, IEC 60068-2-52, EN 50121-4, VCCI Class A, NEMA TS-2, EN 50121-3-2, EN 61326, CISPR 11 class A, EN 61000-4-10, IEC 61850-3, EN 60945

Software / System Requirements

Software Included

Cisco IOS LAN Base

Dimensions & Weight

Width

30.07 cm

Depth

8.15 cm

Height

24.17 cm

Weight

3.3 kg

Manufacturer Warranty

Service & Support

Limited warranty - 5 years

Environmental Parameters

Min Operating Temperature

-40 °C

Max Operating Temperature

60 °C

Humidity Range Operating

5 - 95% (non-condensing)

Min Storage Temperature

-40 °C

Max Storage Temperature

85 °C
