NETGEAR AV Line M4250-10G2XF-PoE++

Name: NETGEAR AV Line M4250-10G2XF-PoE++
Brand: NETGEAR
SKU: ECE6151922
Price: 1969.75 EUR
Availability: InStock

View all NETGEAR Network Switches - Visit the NETGEAR Store (GSM4212UX-100EUS) - (ECE6151922)

Model: NETGEAR AV

AV Line M4250-10G2XF-PoE++ - Switch - L3 - Managed - 10 x 10/100/1000 (8 PoE++) + 2 x 10 Gigabit SFP+ - side to side airflow - rack-mountable - PoE++ (720 W)

Enhanced security
Robust connectivity
Advanced networking
High performance
Reliable operation

FREE Delivery on orders over €250

5 Available to Ship
Order within 12Hrs 48Mins for: FREE Delivery (8 Jun or 9 Jun)

€1969.75 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The NETGEAR M4250 switch series was developed and engineered for audio / video professionals with dedicated service and support. M4250 has been built from the ground up for the growing AV over IP market. AV codecs generally use 1 Gbps or 10 Gbps per stream and the AV Line of M4250 targets the widespread 1 Gbps codecs. PoE++ and rear-facing ports ensure a clean integration in AV racks. M4250 switch comes pre-configured for standard audio and video signals. When requirements are more specific, an AV user interface offers customization with port-based profiles. For audio Dante, Q-SYS and AES67 profiles are available. For video the M4250 offers profiles for NVX, SVSI, Q-SYS, NDI, Dante, as well as audio / video / control mixed profiles.

Features Summary

Enhanced security
With support for SSL 3.0 and TLS 1.2, the NETGEAR M4250-10G2XF-PoE++ ensures secure network communications, safeguarding sensitive data from potential threats.
Robust connectivity
Featuring 10/100/1000 Base-T ports with 8 PoE++ capabilities and 2 10GBase-X SFP+ ports, this switch offers versatile connectivity options for a wide range of devices and high-speed networking requirements.
Advanced networking
Equipped with Layer 3 switching capabilities and a comprehensive set of features such as DHCP snooping, VLAN support, and Quality of Service (QoS), the NETGEAR M4250-10G2XF-PoE++ facilitates efficient network traffic management.
High performance
With a switching capacity of 60 Gbps and firewall throughput of 44.64 Mpps, this switch delivers high-speed data processing and transmission, ensuring optimal network performance.
Reliable operation
Designed for durability and reliability, the NETGEAR M4250-10G2XF-PoE++ operates effectively in a wide range of environmental conditions, supported by its side to side airflow and robust temperature management.

Specification Summary

Product Description

NETGEAR AV Line M4250-10G2XF-PoE++ - switch - 12 ports - Managed - rack-mountable

Device Type

Switch - 12 ports - L3 - Managed

Enclosure Type

Side to side airflow rack-mountable 1U

Subtype

Gigabit Ethernet

Ports

10 x 10/100/1000 (8 PoE++) + 2 x 10 Gigabit SFP+

Power Over Ethernet (PoE)

PoE++

PoE Budget

720 W

Performance

Switching capacity: 60 Gbps ¦ Firewall throughput (64-byte packet size): 44.64 Mpps ¦ Latency (1 Gbps): < 2.14 µs ¦ Latency (10 Gbps): < 0.84 µs

Capacity

VLANs supported: 4093 ¦ ARP entries: 4000 ¦ Multicast entries (IPv4): 512 ¦ Multicast entries (IPv6): 128 ¦ Jumbo frame size: up to 12000 ¦ IGMP multicast groups: 2000 ¦ MSTP instances: 16 ¦ PVST instances: 32

MAC Address Table Size

16K entries

Routing Protocol

RIP, IGMP, IGMPv2, IGMPv3, MLDv2, static IPv4 routing, static IPv6 routing, PIM-DM, PIM-SM, PIM-SSM

Remote Management Protocol

CLI, SNMP, HTTPS, Telnet, SSH, RADIUS, TACACS+, RMON 1, RMON 2, RMON 9

Features

16MB packet buffer, RSPAN, PIM, DHCP server, policy based routing, LLDP-MED, MVRP, STP support, Rapid Reconfiguration of Spanning Tree (RSTP), BPDU, STRG, VLAN support, GVRP, GMRP, LACP, LAG, Private VLAN, DHCP snooping, DAI, IP source guard, DHCP relay, AAA, sFlow, QoS, DoS attack prevention

Compliant Standards

IEEE 802.1ak, IEEE 802.1as, IEEE 802.1Qat, IEEE 802.1Qav, IEEE 802.3az, IEEE 802.1ab (LLDP), IEEE 802.1AX, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt

Dimensions (WxDxH)

44 cm x 25.7 cm x 4.32 cm

Weight

3.83 kg

Localisation

Europe

Manufacturer Warranty

ProSAFE lifetime warranty

Specifications

EAN / GTIN:

606449149623

General

Device Type

Switch - 12 ports - L3 - Managed

Enclosure Type

Side to side airflow rack-mountable 1U

Subtype

Gigabit Ethernet

Ports

10 x 10/100/1000 (8 PoE++) + 2 x 10 Gigabit SFP+

Power Over Ethernet (PoE)

PoE++

PoE Budget

720 W

Performance

Switching capacity: 60 Gbps ¦ Firewall throughput (64-byte packet size): 44.64 Mpps ¦ Latency (1 Gbps): < 2.14 µs ¦ Latency (10 Gbps): < 0.84 µs

Capacity

MAC Address Table Size

16K entries

Routing Protocol

RIP, IGMP, IGMPv2, IGMPv3, MLDv2, static IPv4 routing, static IPv6 routing, PIM-DM, PIM-SM, PIM-SSM

Remote Management Protocol

CLI, SNMP, HTTPS, Telnet, SSH, RADIUS, TACACS+, RMON 1, RMON 2, RMON 9

Encryption Algorithm

TLS 1.2, SSL 3.0

Features

Compliant Standards

IEEE 802.1ak, IEEE 802.1as, IEEE 802.1Qat, IEEE 802.1Qav, IEEE 802.3az, IEEE 802.1ab (LLDP), IEEE 802.1AX, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt

Processor

X ARM A9: 1.25 GHz

RAM

2 GB

Flash Memory

256 MB

Status Indicators

Link/activity, PoE, speed

Expansion / Connectivity

Interfaces

10 x 10/100/1000 Base-T RJ-45 8 ports (PoE++) ¦ 2 x 10GBase-X SFP+ ¦ 1 x management (Gigabit LAN) RJ-45 ¦ 1 x console RJ-45 ¦ 1 x USB Type A ¦ 1 x console (USB) Type C

Power

Power Device

Internal power supply

Installed Qty

Power Consumption Operational

26.3 watt

Power Consumption Stand by

18 watt

Miscellaneous

Included Accessories

Mounting brackets, 2 x SFP slot caps, foot pad set

Cables Included

Console cable ¦ USB-C to USB-A cable

Rack Mounting Kit

Included

Compliant Standards

IEEE 1588, AN/NZS 60950.1:2015, ANSI C63.4:2014, AS/NZS CISPR32:2013 Class A, CCC, CISPR 32:2012, CNS 13438 Class A, CNS 14336-1, EN 55024:2010, EN 55032:2012+AC:2013 Class A, EN 60950-1:2006+A1:2010+A11:2009+A2:2013+A12:2011, EN 61000-3-2:2014 Class A, EN 61000-3-3:2013, FCC CFR47 Part 15 B Class A, GB 4943.1-2011, GB/T9254-2008 Class A, ICES-003:2016 issue 6 Class A, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, IEC60950/EN60950, VCCI-CISPR 32:2016 Class A, YD/T993-1998

Localisation

Europe

Dimensions & Weight

Width

44 cm

Depth

25.7 cm

Height

4.32 cm

Weight

3.83 kg

Manufacturer Warranty

Service & Support

Limited warranty - lifetime

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

45 °C

Humidity Range Operating

90% (non-condensing)

Min Storage Temperature

-20 °C

Max Storage Temperature

70 °C

Humidity Range Storage

95% (non-condensing)
