Device Type
Switch - 8 ports - L3 Lite - smart
Performance
Bandwidth: 16 Gbps
Capacity
VLANs supported: 64 ¦ Multicast groups: 128
MAC Address Table Size
4000 entries
Routing Protocol
IGMP, IGMPv2, IGMPv3
Remote Management Protocol
TFTP
Features
SOHO, QoS, IGMP snooping, VLAN support, DoS attack prevention, rate limit, port mirroring, Jumbo Frames support, 192KB packet buffer, store and forward, WRR, port-based VLAN, block unknown multicast, DHCP client, CoS, cable test, auto-uplink (auto MDI/MDI-X), Auto Negotiation, fanless, password protection
Compliant Standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x
Status Indicators
Port transmission speed, link/activity, system, power
Interfaces
8 x 1000Base-T RJ-45 PoE+
Power Device
External power adapter
Power Consumption Operational
3.7 Watt
Compliant Standards
Plug and Play, FCC Part 15 Class B, EN 55032, VCCI, ACMA, EN55024
Service & Support
Limited warranty - 5 years ¦ Technical support - phone consulting - 90 days
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
90% (non-condensing)
Min Storage Temperature
-20 °C
Max Storage Temperature
70 °C
Humidity Range Storage
95% (non-condensing)
