EAN / GTIN:
4718937607372
Device Type
Switch - 8 ports - Managed
Enclosure Type
Rack-mountable, wall-mountable
Ports
8 x 10/100/1000 + 2 x combo Gigabit SFP
Performance
Switching capacity: 20 Gbps ¦ Forwarding rate: 15 Mpps ¦ Packet buffer size: 1.5 MB
MAC Address Table Size
16K entries
Routing Protocol
IGMPv2, IGMP, IGMPv3, static IPv4 routing, static IPv6 routing, MLD, MSTP, RSTP, STP
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, TFTP, SSH-2, CLI, NTP, ICMP, DHCP, RSTP, TACACS+, RADIUS
Authentication Method
RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Features
Flow control, IGMP snooping, Syslog support, port mirroring, IP address filtering, ZyXEL iStacking Technology, sFlow, QoS, MLD snooping, fanless, LACP support, LLDP support, DHCP relay, Port Security, DHCP client, MIB, MVR, port isolation, CoS, GVRP, cloud managed, DSCP support, ErrDisable Recovery, IP source guard, ARP inspection, dual image support, Root Guard, Loop Guard, LLDP-MED, EEE, VLAN Tagging, MRSTP
Compliant Standards
IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3az
Interfaces
10 x 1000Base-T RJ-45 ¦ 2 x 1000Base-X SFP ¦ 1 x serial (RS-232)
Power Device
Internal power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
11 Watt
Included Accessories
Wall mounting kit
Rack Mounting Kit
Included
Compliant Standards
BSMI, RoHS, FCC Part 15 A, LVD, EMC Class A
Localisation
United Kingdom
Dimensions & Weight (Shipping)
Service & Support
Limited warranty - lifetime
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Humidity Range Operating
10 - 95%
