Zyxel GS1900-48HP

View all ZYXEL Network Switches - Visit the ZYXEL Store (GS190048HPV2-GB0101F) - (MMECA65592)

GS1900-48HP - switch - 48 ports - smart - rack-mountable

Versatility and flexibility for different needs
Simple, intuitive wizard set up
Avoiding network errors with easy management
Energy saving for IEEE 802.3az
Intelligence to power more devices

FREE Delivery on orders over €250

11 Available to Ship
Order within 0Hrs 16Mins for: FREE Delivery (8 Jun or 9 Jun)

€479.75 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The ZyXEL GS1900 series of 48-port GbE Smart Managed Switch with Gigabit speed and essential managing functions bring your business network more flexibility and connectivity. Providing GbE switches with power saving functions, fanless design and full IPv6 support ensure your network to be ready for future expansions. In addition, the PoE models GS1900-48HP Gigabit switch complies with the IEEE 802.3at Power over Ethernet (PoE) Plus standard. The complete GS1900 series has been designed with useful features and advanced performances that empower your networks with speed and security as well as silent operation in your office environments.

Specification Summary

Product Description

Zyxel GS1900-48HP - switch - 48 ports - smart - rack-mountable

Device Type

Switch - 48 ports - smart

Enclosure Type

Rack-mountable

Subtype

Gigabit Ethernet

Ports

24 x 10/100/1000 + 24 x 10/100/1000 (PoE+) + 2 x Gigabit SFP

Power Over Ethernet (PoE)

PoE+

PoE Budget

170 W

Performance

Switching capacity: 100 Gbps ¦ Forwarding performance: 74 Mpps

MAC Address Table Size

8K entries

Jumbo Frame Support

9KB

Routing Protocol

IGMP, IGMPv2, IGMPv3

Remote Management Protocol

RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2, SNMP 3

Features

Fanless, Energy Efficient Ethernet, 1.5MB packet buffer, Syslog support, MIB, LLDP support, flow control, auto-uplink (auto MDI/MDI-X), CoS, IGMP snooping, LACP support, per port bandwidth control, Port Security, QoS, store and forward, SPQ, tagged VLAN, VLAN support, WRR queuing, DoS attack prevention, IPv6 support

Compliant Standards

IEEE 802.3az, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.1ab (LLDP), IEEE 802.3af, IEEE 802.3at

Power

AC 100-240 V (50/60 Hz)

Dimensions (WxDxH)

44.1 cm x 31 cm x 4.4 cm

Weight

3.55 kg

Localisation

United Kingdom

Manufacturer Warranty

Limited lifetime warranty

Specifications

EAN / GTIN:

4718937609550

General

Device Type

Switch - 48 ports - smart

Enclosure Type

Desktop, rack-mountable, wall-mountable

Subtype

Gigabit Ethernet

Ports

24 x 10/100/1000 + 24 x 10/100/1000 (PoE+) + 2 x Gigabit SFP

Power Over Ethernet (PoE)

PoE+

PoE Budget

170 W

Performance

Switching capacity: 100 Gbps ¦ Forwarding performance: 74 Mpps

MAC Address Table Size

8K entries

Jumbo Frame Support

9KB

Routing Protocol

IGMP, IGMPv2, IGMPv3

Remote Management Protocol

RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2, SNMP 3

Encryption Algorithm

SSL

Authentication Method

RADIUS, TACACS+

Features

Compliant Standards

IEEE 802.3az, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.1ab (LLDP), IEEE 802.3af, IEEE 802.3at

Status Indicators

Power, system, link/activity

Expansion / Connectivity

Interfaces

24 x 1000Base-T RJ-45 PoE+ ¦ 2 x SFP ¦ 24 x 1000Base-T RJ-45

Power

Power Device

Internal power supply

Voltage Required

AC 100-240 V (50/60 Hz)

Power Consumption Operational

220.5 Watt

Miscellaneous

MTBF

612,215 hours

Compliant Standards

BSMI CNS 13438, BSMI CNS 14336, C-Tick Class A, EN 60950-1, FCC Class B certified, RoHS

Localisation

United Kingdom

Dimensions & Weight

Width

44.1 cm

Depth

31 cm

Height

4.4 cm

Weight

3.55 kg

Dimensions & Weight (Shipping)

Shipping Width

62.2 cm

Shipping Depth

35.8 cm

Shipping Height

10.8 cm

Manufacturer Warranty

Service & Support

Limited warranty - lifetime

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

50 °C

Humidity Range Operating

10 - 95% (non-condensing)

Min Storage Temperature

-40 °C

Max Storage Temperature

70 °C
