Overview

Range/Series Overview


IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The Zyxel GS-105B is designed to meet the networking needs of small to medium-sized enterprises with its robust performance and reliability. This 5-port Gigabit Ethernet switch delivers a switching capacity of 10 Gbps and a forwarding rate of 7.4 Mpps, ensuring efficient data transfer across the network. Its compact form factor is suitable for desktop use or wall mounting, making it a flexible choice for various environments. Operating within a temperature range of 0°C to 40°C and featuring a high packet buffer size of 128 KB, this switch is built to handle demanding network conditions. The device complies with multiple standards, including IEEE 802.3 and FCC, which ensures compatibility and performance in different network settings. With additional features such as Quality of Service (QoS) and auto-uplink capability, the GS-105B is an effective solution for enhancing network performance.


Specification Summary

Product Description
Zyxel GS-100 series GS-105B - Version 5 - switch - 5 ports - unmanaged
Device Type
Switch - 5 ports - unmanaged
Subtype
Gigabit Ethernet
Ports
5 x 10/100/1000
Performance
Switching capacity: 10 Gbps ¦ Forwarding rate: 7.4 Mpps ¦ Packet buffer size: 128 KB
MAC Address Table Size
2K entries
Jumbo Frame Support
9KB
Features
Fanless, auto-uplink (auto MDI/MDI-X), store and forward, QoS, Energy Efficient Ethernet
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3x
Dimensions (WxDxH)
8.25 cm x 4.68 cm x 2.4 cm
Weight
110 g
Localisation
United Kingdom

Specifications

EAN / GTIN:
4718937638925
General
Device Type
Switch - 5 ports - unmanaged
Enclosure Type
Desktop, wall-mountable
Subtype
Gigabit Ethernet
Ports
5 x 10/100/1000
Performance
Switching capacity: 10 Gbps ¦ Forwarding rate: 7.4 Mpps ¦ Packet buffer size: 128 KB
MAC Address Table Size
2K entries
Jumbo Frame Support
9KB
Features
Fanless, auto-uplink (auto MDI/MDI-X), store and forward, QoS, Energy Efficient Ethernet
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3x
Status Indicators
Power, link/activity
Expansion / Connectivity
Interfaces
1 x 1000Base-T RJ-45 high priority ¦ 2 x 1000Base-T RJ-45 medium priority ¦ 2 x 1000Base-T RJ-45
Power
Power Device
External power adapter
Power Consumption Operational
2.99 Watt
Power Consumption Stand by
0.44 Watt
Miscellaneous
Included Accessories
Power adapter, rubber feet, wall mounting kit
MTBF
259,047 hours
Compliant Standards
EAC, FCC, BSMI Class B
Localisation
United Kingdom
Dimensions & Weight
Width
8.25 cm
Depth
4.68 cm
Height
2.4 cm
Weight
110 g
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
5 - 95% (non-condensing)
