Eaton Ellipse PRO 1200 - UPS - 750 watt - 1200 VA

Images Manuals

Images for illustrative purposes

Eaton Ellipse PRO 1200

Name: Eaton Ellipse PRO 1200
Brand: EATON
SKU: ECE2765455
Price: 414.41 EUR
Availability: InStock

View all EATON Uninteruptable Power Supply - Visit the EATON Store (ELP1200IEC) - (ECE2765455)

Model: Eaton Ellipse

Ellipse PRO 1200 - UPS - AC 230 V - 750 watt - 1200 VA - 7 Ah - USB - output connectors: 8 - 2U - 19"

FREE Delivery on orders over €250

**Note: There may be an extra delivery charge on some very large UPS, we will notify you if this is the case. Please ensure you are buying the correct UPS or Battery, once a UPS or Battery is opened it cannot be returned. Please contact sales through email, chat or phone if you need to confirm.

13 Available to Ship
Order within 16Hrs 55Mins for: FREE Delivery (8 Jun or 9 Jun)

€414.41 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The Eaton Ellipse PRO 1200, 1200 VA, is a line interactive UPS specifically developed to protect workstations with demanding applications. As well as providing a power supply backed up by a battery to keep equipment operating during a power failure, the Ellipse PRO also provides effective protection against damaging surges.

The Ellipse PRO features a LCD display for real time status and measurements. This model includes 2 Eco Control power outlets, that enable energy savings up to 20 percent. It complies fully with the requirements of the IEC 616431-1 standard. This UPS can be either placed as a tower, in a rack or be wall mounted. The Ellipse PRO also includes the Eaton Intelligent Power Manager software. It is an ideal protection for all business computers.

Specification Summary

Product Description

Eaton Ellipse PRO 1200 - UPS - 750 watt - 1200 VA

Device Type

UPS - external

Rack Size

19" - 2U

Weight

9.9 kg

Input Voltage

AC 230 V

Output Voltage

AC 220/230/240 V + 15% / - 20%

Power Capacity

750 watt / 1200 VA

Input Connectors

1 x power IEC 60320 C14

Output connectors

4 x power IEC 60320 C13 (UPS and surge) ¦ 4 x power IEC 60320 C13 (surge)

Battery

Lead Acid - 7 Ah

Batteries Qty

Run Time (Up To)

9 min at half load

Networking

USB

Dimensions (WxDxH)

8.2 cm x 39 cm x 27.5 cm

Manufacturer Warranty

3-year warranty

Specifications

EAN / GTIN:

743172437952

General

Device Type

UPS - external

Height (Rack Units)

Rack Size

19"

Power Device

UPS Technology

Line interactive

Input Voltage

AC 230 V

Input Voltage Range

AC 165 - 285 V

Input Voltage Range (Adjustable)

AC 150 - 285 V

Frequency Provided

50/60 Hz

Frequency Required

50/60 Hz

Input Connectors

1 x power IEC 60320 C14

Power Output Connectors Details

4 x power IEC 60320 C13 (UPS and surge) ¦ 4 x power IEC 60320 C13 (surge)

Output Voltage

AC 220/230/240 V + 15% / - 20% - 50/60 Hz

Power Capacity

750 watt / 1200 VA

Dataline Surge Protection

Network/phone line - RJ-45/RJ-11 - 1 input line / 1 output line

Surge Suppression

Yes

Circuit Protection

Circuit breaker

Battery

Quantity

Technology

Lead Acid

Capacity

7 Ah

Run Time (Up To)

9 min at half load ¦ 5 min at 70% load

Networking

Remote Management Interface

USB

Expansion / Connectivity

Interfaces

1 x management (USB) - 4 pin USB Type B

Miscellaneous

Cables Included

USB cable - external

Rack Mounting Kit

Optional

Features

Wall mountable, LCD display, Automatic Voltage Regulation (AVR), deep discharge protection, cold-start function, EcoControl Master/Control outlets

Compliant Standards

CB, IEC 62040-1-1, IEC 62040-2, IEC 61643-1, EN 62040-1-1, EN 62040-2

Software / System Requirements

Software Included

Eaton UPS Companion

Manufacturer Warranty

Service & Support

Limited warranty - 3 years ¦ Limited warranty - batteries - 3 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

35 °C

Humidity Range Operating

0 - 85%

Dimensions & Weight

Width

8.2 cm

Depth

39 cm

Height

27.5 cm

Weight

9.9 kg
