Overview

Range/Series Overview


IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The EloPOS Z30 offers a dynamic all-in-one solution for point of sale environments with its sleek 15.6-inch Full HD LED display. Featuring 10-point multi-touch functionality, this system ensures a responsive and intuitive user experience. The robust Intel Pentium J6426 processor, with a quad-core configuration and clock speeds up to 3 GHz, enables smooth operation and efficient multitasking, supporting demanding applications in retail or hospitality settings.

With 256 GB of SSD storage, the EloPOS Z30 provides ample space for essential data and optimizes performance with NVM Express technology. The integrated stereo sound output, enhanced by two built-in speakers, offers clear audio support for informative displays or multimedia applications. Connectivity is a strong suit with multiple USB ports, DisplayPort/USB-C, and wireless options, including Bluetooth 5.2, ensuring versatile integration into any modern workspace.


Specification Summary

Product Description
EloPOS Z30 Standard - all-in-one Pentium J6426 2 GHz - 8 GB - SSD 256 GB - LED 15.6"
Type
Point of sale terminal - all-in-one
Processor
1 x Intel Pentium J6426 / 2 GHz (up to 3 GHz, (Quad-Core)
Cache Memory
1.5 MB L2 Cache
Cache Per Processor
1.5 MB
RAM
8 GB (installed) / 32 GB (max) - DDR4 SDRAM
Hard Drive
SSD 256 GB - PCI Express 4.0 - NVM Express (NVMe)
Optical Storage
No optical drive
Monitor
15.6" - LED - 1920 x 1080 (Full HD) @ 60 Hz - 16:9 - touchscreen
Audio Output
Stereo
Networking
1GbE, 802.11a, Wi-Fi 5, 802.11b/g/n, Bluetooth 5.2
Power
(50/60 Hz)
OS Provided
Windows 11
Software Included
Google Play Services
Colour
Dark grey metallic
Dimensions (WxDxH)
36.28 cm x 18.04 cm x 29.87 cm
Weight
4 kg
Manufacturer Warranty
Limited warranty - 3 years

Specifications

EAN / GTIN:
0843173163659
General
Type
Point of sale terminal
Product Form Factor
All-in-one
Colour
Dark grey metallic
Processor / Chipset
CPU
Intel Pentium J6426
Clock Speed
2 GHz
Max Turbo Speed
3 GHz
Number of Cores
Quad-Core
CPU Qty
1
Max CPU Qty
1
Cache Memory
Installed Size
L2 Cache - 1.5 MB
Cache Per Processor
1.5 MB
RAM
Installed Size
8 GB (installed) / 32 GB (max)
Technology
DDR4 SDRAM
Effective Memory Speed
3200 MHz
Rated Memory Speed
3200 MHz
Form Factor
SO-DIMM 260-pin
Slots
1 (Total) / 0 (empty)
Configuration Features
1 x 8 GB
Hard Drive
Type
SSD
Capacity
1 x 256 GB
Interface Type
PCI Express 4.0
Features
NVM Express (NVMe)
Optical Storage
Type
No optical drive
Monitor
Monitor Type
LED
Touchscreen
Yes (10-point multi-touch)
Diagonal Size
15.6"
Native Resolution
1920 x 1080 (Full HD)
V-Sync Rate at Max Res.
60 Hz
Widescreen Display
Yes
Image Aspect Ratio
16:9
Horizontal Viewing Angle
170
Vertical Viewing Angle
170
Response Time
20 ms
Image Brightness
280 cd/m²
Image Contrast Ratio
1000:1
Monitor Features
TouchPro Pro Projected Capacitive (PCAP) technology, 8-bit gamma
Audio Output
Sound Output Mode
Stereo
Speakers Included
2
Audio Input
Type
Dual array microphone
Networking
Wireless LAN Supported
Yes
Data Link Protocol
Ethernet, Gigabit Ethernet, Fast Ethernet, IEEE 802.11g, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11n, Bluetooth 5.2
Compliant Standards
IEEE 802.11g, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n, IEEE 802.11b, Bluetooth 5.0
Expansion / Connectivity
Interfaces
4 x USB 3.0 (900 mA) ¦ 1 x DisplayPort/USB-C (27 Watt charging) ¦ 1 x cash drawer - RJ-12 (12V/24 V) ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x USB 2.0 (powered (DC 24V))
Miscellaneous
Included Accessories
Power adapter, 2 x zip ties, screw set, base plate
VESA Mounting Interface
VESA, 75 mm
Compliant Standards
UL, cUL, FCC Class B certified, IC, CB, VCCI, MIC, RCM
Power
Device Type
Power adapter
Voltage Required
AC 100-240 V (50/60 Hz)
Power Provided
150 Watt
Power Consumption Operational
20 Watt
Power Consumption Stand by
0.5 Watt
Power Consumption Sleep
4.7 Watt
Operating System / Software
OS Provided
Windows 11
Software
Google Play Services
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Dimensions & Weight
Width
36.28 cm
Depth
18.04 cm
Height
29.87 cm
Weight
4 kg
Dimensions & Weight (Shipping)
Shipping Width
46 cm
Shipping Depth
39.9 cm
Shipping Height
27 cm
Shipping Weight
6.4 kg
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 90%
