EAN / GTIN:
0790069470653
Device Type
Switch - 8 ports - Managed
Enclosure Type
Rack-mountable 1U
Ports
8 x 10/100/1000 (PoE++) + 2 x Gigabit SFP
Power Over Ethernet (PoE)
PoE++
Performance
Switching capacity: 20 Gbps ¦ Forwarding rate: 14.88 Mbps
Capacity
Packet buffer size: 4.1 Mbit ¦ VLAN groups: 128 ¦ IGMP snooping groups: 64 ¦ Link aggregation groups: 8 ¦ Link aggregation ports: 8 ¦ Queues per port: 4
MAC Address Table Size
8K entries
Jumbo Frame Support
10240 bytes
Routing Protocol
STP, IGMP, IGMPv2, RSTP
Remote Management Protocol
SNMP, MIB, RSTP, IPv4, IPv6, DHCP
Features
6KV Surge protection, 1 fan, Smart Fan, Auto Surveillance VLAN, ONVIF support, built-in DIP switch, QoS, isolate mode, PD-Alive, MDI, half duplex mode, MDI-X, full duplex mode, auto-negotiation, flow control, Voice VLAN, port-based VLAN, tagged VLAN, Asymmetric VLAN, ERPS, loopback detection, Cable Diagnostics Function, LLDP support, port mirroring, STP support, WRR, rate limit, Broadcast Storm Control, Multicast Storm Control, Storm Control, Unicast Storm Control, Unknown Storm Control, static IP mode, IGMP snooping, BOOTP support, Private MIB, MIB II, MIB
Compliant Standards
IEEE 802.3bt, IEEE 802.3af, IEEE 802.3at, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1w, IEEE 802.1p
Status Indicators
Power, link/activity/speed, alarm
Interfaces
8 x 10/100/1000 Base-T RJ-45 PoE++ - 90 W ¦ 2 x 1000Base-T SFP
Power Device
Internal power supply
Voltage Required
AC 100-240 V (50/60 Hz)
Power Consumption Stand by
10.7 Watt
Rack Mounting Kit
Included
Compliant Standards
FCC, BSMI, cUL, UL, LVD, CB, BMSI, RFC768, RFC791, RFC792, RFC793, RFC826, RFC1213, RFC1493, RFC1907, RFC1215, RFC2233, RFC2665, RFC4363, RFC951, RFC1542, RFC2236, NDAA
Localisation
United Kingdom
Service & Support
Limited warranty - lifetime
Min Operating Temperature
-5 °C
Max Operating Temperature
50 °C
Humidity Range Operating
0 - 95% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
0 - 95% (non-condensing)
