V7 - docking station - USB-C - VGA, HDMI, DP - 1Gb

Images Manuals

Images for illustrative purposes

V7

View all VIDEOSEVEN Docking | Replicator - Visit the VIDEOSEVEN Store (DOCKUCPT01) - (MMECP15755)

V7 - docking station - USB-C - VGA, HDMI, DP - 1GbE

Versatile connectivity options
High-resolution support
Efficient power delivery
Robust environmental range
Enhanced security features

FREE Delivery on orders over €250

SPO - THIS IS A SPECIAL ORDER ITEM AND CANNOT BE RETURNED AS UNWANTED OR CANCELLED.

1093 Available to Ship
Order within 7Hrs 28Mins for: Delivery (8 Jun or 9 Jun)

€18.86 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The DOCKUCPT01 USB-C Pass Through Docking Station from V7 allows you to add up to 3 displays, Audio, Gigabit Ethernet, SD/Micro SD/MMC memory cards, and extra USB ports to almost any USB-C enabled device. It features HDMI, DisplayPort and VGA display outputs that can be used to expand or mirror your device for multitasking productivity. It has a USB-C PD charging port to connect a USB-C Power supply which can supply up to 100 Watts of USB-C Charging to your computer at the same time as providing all the extra connectivity. It is compatible with DisplayPort Alt mode, USB-C and Thunderbolt 3 host computers, mobile devices, or other devices.

Specification Summary

Product Description

V7 - docking station - USB-C - VGA, HDMI, DP - 1GbE

Product Type

Docking station

Docking Interface

USB-C

Video Interfaces

VGA, HDMI, DP

Dimensions (WxDxH)

7.4 cm x 34.95 cm x 1.8 cm

Colour

Black

Networking

Gigabit Ethernet

Manufacturer Warranty

2-year warranty

Specifications

EAN / GTIN:

0662919111934

General

Product Type

Docking station

Width

7.4 cm

Depth

34.95 cm

Height

1.8 cm

Enclosure Colour

Black

Video

Max Resolution Details

4K - 30 Hz (HDMI only) ¦ 1920 x 1200 - 60 Hz (VGA only) ¦ 4K - 30 Hz (DisplayPort only)

Networking

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet

Expansion / Connectivity

Expansion Slots

1 (total) / 1 (free) x SD Memory Card ¦ 1 (total) / 1 (free) x microSD

Interfaces

1 x USB-C with Power Delivery (100 W) - 24 pin USB-C ¦ 1 x audio / video - HDMI - 19 pin HDMI Type A ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x headphone/microphone combo jack - mini-phone stereo 3.5 mm ¦ 1 x audio / video - VGA - 15 pin HD D-Sub (HD-15) ¦ 1 x audio / video - DisplayPort - 20 pin DisplayPort ¦ 3 x SuperSpeed USB 3.0 - 9 pin USB Type A ¦ 2 x USB 2.0 - 4 pin USB Type A ¦ 1 x USB-C - 24 pin USB-C

Miscellaneous

Cables Included

1 x USB-C cable - external

Features

Security lock slot (cable lock sold separately), MST (multi-stream transport), pass-through charging

Security Slot Type

Kensington security slot

Compliant Standards

FCC, HDCP 1.4, UKCA

Manufacturer Warranty

Service & Support

Limited warranty - 2 years
