V7 DOCKTB4PT - docking station - Thunderbolt 4 - 2

Images Manuals

Images for illustrative purposes

V7 DOCKTB4PT

View all VIDEOSEVEN Docking | Replicator - Visit the VIDEOSEVEN Store (DOCKTB4PT) - (MMECP15689)

V7 DOCKTB4PT - docking station - Thunderbolt 4 - 2 x DP, 2 x HDMI - 2.5GbE, 1GbE

Versatile connectivity options
High-resolution support
Efficient power delivery
Robust environmental compliance
Reliable temperature operation

FREE Delivery on orders over €250

SPO - THIS IS A SPECIAL ORDER ITEM AND CANNOT BE RETURNED AS UNWANTED OR CANCELLED.

326 Available to Ship
Order within 9Hrs 53Mins for: Delivery (8 Jun or 9 Jun)

€59.75 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

This DOCKTB4PT Thunderbolt 4 Triple Alt Mode Display Docking Station from V7 adds up to 3 displays, 3 USB ports, 2 Thunderbolt 4 ports, a USB-C port with up to 96 Watts Power Delivery, Audio, SD/Micro SD Memory Cards and up to 2.5 Gigabit Ethernet network connectivity to your Thunderbolt 4 enabled computer while charging at the same time with up to 96W power delivery. It features two HDMI ports and two DisplayPort outputs that can be used to extend or mirror your device for multitasking productivity. It supports single 8K 30Hz display (HDMI or DP) or up to three 4K (4K/60Hz + 4K/60Hz + 4K/30Hz) displays. It is Thunderbolt 4 certified and compatible with DisplayPort Alt mode and USB4 enabled computers and mobile devices. It includes both K-Lock and N-Lock interface for security. This solution provides high performance connectivity to extend and enhance your workstation productivity with a 2 year warranty.

Specification Summary

Product Description

V7 DOCKTB4PT - docking station - Thunderbolt 4 - 2 x DP, 2 x HDMI - 2.5GbE, 1GbE

Product Type

Docking station - for notebook, desktop, tablet

Docking Interface

Thunderbolt 4

Video Interfaces

2 x DP, 2 x HDMI

Dimensions (WxDxH)

8.5 cm x 22.5 cm x 2.2 cm

Weight

499 g

Colour

Silver, black

Networking

2.5 Gigabit Ethernet, Gigabit Ethernet

Power

Power adapter 150 Watt Power Provided (DC 20 V)

Manufacturer Warranty

2-year warranty

Specifications

EAN / GTIN:

0662919116199

General

Product Type

Docking station - for notebook, desktop, tablet

Width

8.5 cm

Depth

22.5 cm

Height

2.2 cm

Weight

499 g

Enclosure Colour

Silver, black

Video

Max Resolution Details

8K - 30 Hz (Single Display (DisplayPort / HDMI)) ¦ 4K - 30 Hz (Triple Display) ¦ 4K - 60 Hz (Dual Display)

Networking

Data Link Protocol

2.5 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet

Compliant Standards

IEEE 802.3bz, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3az

Expansion / Connectivity

Interfaces

2 x audio / video - DisplayPort - 20 pin DisplayPort ¦ 1 x network - RJ-45 ¦ 2 x audio / video - HDMI - 19 pin HDMI ¦ 1 x microphone / audio - mini-phone 3.5 mm ¦ 2 x USB 3.2 Gen 2 - 9 pin USB Type A ¦ 1 x USB 3.2 Gen 1 - 9 pin USB Type A ¦ 1 x USB-C 3.2 Gen 2 with Power Delivery (96 W) - 24 pin USB-C ¦ 2 x Thunderbolt 4 - 24 pin USB-C

Miscellaneous

Input Device

microSD card reader, SD card reader

Cables Included

1 x Thunderbolt 4 cable - detachable - 80 cm

Features

ABS housing, LED indicator, high resolution support, 2 security lock slots (cable lock sold separately), DisplayPort Alt Mode

Security Slot Type

Kensington nano security slot / Kensington security slot

Compliant Standards

RoHS, FCC
