Startech USB C Multiport Adapter, HDMI 4K 30Hz or VGA Travel Dock, 5Gbps USB 3.0 Hub (USB A / USB C Ports), 100W Power Delivery, SD/MicroSD Slot, GbE,

Images for illustrative purposes

Startech USB C Multiport Adapter, HDMI 4K 30Hz or VGA Travel Dock, 5Gbps USB 3.0 Hub (USB A / USB C Ports), 100W Power Delivery, SD/MicroSD Slot, GbE,

View all STARTECH.COM Docking | Replicator - Visit the STARTECH.COM Store (DKT30CHVSDPD) - (ECE7254685)

Startech USB C Multiport Adapter, HDMI 4K 30Hz or VGA Travel Dock, 5Gbps USB 3.0 Hub (USB A / USB C Ports), 100W Power Delivery, SD/MicroSD Slot, GbE, 12" (30cm) Long Attached Cable - USB C Mini Dock - Docking station - USB-C 3.2 Gen 1 - VGA, HDMI - 1GbE

Enhance Productivity
Connect Your Devices
Built-In SD Card Reader
Charge Your Laptop and Peripherals
Reliable Network Connectivity

FREE Delivery on orders over €250

3 Available to Ship
Order within 16Hrs 7Mins for: Delivery (8 Jun or 9 Jun)

€31.83 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

This USB-C multiport adapter supports 4K 30Hz HDMI or 1080p VGA and turns your MacBook Pro, Dell XPS, or other USB-C laptops or tablet into a workstation, anywhere you go. The USB Type-C multiport adapter provides 4K HDMI or 1080p VGA video output, two USB 3.1 Gen 1 Type-A (5Gbps) ports (including 1x Fast Charge port), a single USB 3.1 Gen 1 Type-C (5Gbps) port, an SD/MicroSD card reader and a Gigabit Ethernet port, all through one connection to your laptop's USB-C or Thunderbolt 3/4 port. Plus, it offers advanced charging through USB Power Delivery 3.0 and an extra-long attached 12-inch (30 cm) host cable for an extended reach to offer more set up flexibility. USB 3.1 Gen 1 (5Gbps) is also known as USB 3.2 Gen 1 (5Gbps) and USB 3.0 (5Gbps).

Features Summary

Enhance Productivity
The portable docking station offers versatile video flexibility by connecting your laptop to a 4K 30Hz HDMI monitor (4096 x 2160p) or a 1080p (60Hz) VGA monitor (1920x1080) to create a powerful workstation. For added video flexibility, the dock also supports ultra-wide monitors.
Connect Your Devices
The USB-C to USB 3.1 Gen 1 hub gives you two USB-A (5Gbps) ports and one USB-C (5Gpbs) port to connect your USB devices.
Built-In SD Card Reader
Access your multimedia content with ease. The multiport adapter provides direct access to your SD, SDHC and SDXC memory cards or microSD (uSD) cards.
Charge Your Laptop and Peripherals
With support for USB PD 3.0 (up to 100W), the USB Type-C multiport adapter lets you power and charge your laptop when a power adapter is connected to the USB-C power input port. Plus, one of the USB-A (5Gbps) ports supports BC 1.2 fast charge to power your peripherals when the dock is connected to a USB-C power adapter. PD 3.0 features Fast Role Swap to prevent USB, Ethernet and video disruption when you switch power sources (USB-C power adapter to bus power).
Reliable Network Connectivity
The Gigabit Ethernet port ensures reliable wired network access with support for PXE Boot and WoL.

Specification Summary

Product Description

Startech USB C Multiport Adapter, HDMI 4K 30Hz or VGA Travel Dock, 5Gbps USB 3.0 Hub (USB A / USB C Ports), 100W Power Delivery, SD/MicroSD Slot, GbE, 12" (30cm) Long Attached Cable - USB C Mini Dock - docking station - USB-C 3.2 Gen 1 - VGA, HDMI - 1GbE

Product Type

Docking station

Docking Interface

USB-C 3.2 Gen 1

Video Interfaces

VGA, HDMI

Dimensions (WxDxH)

5.9 cm x 1.4 cm

Weight

137 g

Colour

Space grey

Networking

Gigabit Ethernet

Manufacturer Warranty

3-year warranty

Specifications

EAN / GTIN:

0065030891769

General

Product Type

Docking station

Depth

5.9 cm

Height

1.4 cm

Weight

137 g

Enclosure Colour

Space grey

Video

Max Resolution Details

4096 x 2160 - 30 Hz (HDMI only) ¦ 1920 x 1080 - 60 Hz (VGA only)

Networking

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, USB 3.0, USB 3.1 Gen 1, USB 3.2 Gen 1

Expansion / Connectivity

Expansion Slots

1 (total) / 1 (free) x SD Memory Card ¦ 1 (total) / 1 (free) x microSD

Interfaces

1 x display / video - HDMI - 19 pin HDMI Type A ¦ 1 x display / video - VGA - 15 pin HD D-Sub (HD-15) ¦ 1 x USB 3.2 Gen 1 with Battery Charging 1.2 - 9 pin USB Type A ¦ 1 x USB 3.2 Gen 1 - 9 pin USB Type A ¦ 1 x USB-C 3.2 Gen 1 - 24 pin USB-C ¦ 1 x USB-C 3.2 Gen 1 with Power Delivery 3.0 (100 W) - 24 pin USB-C ¦ 1 x network - 1000Base-T - RJ-45

Miscellaneous

Input Device

SD card reader, microSD card reader

Cables Included

1 x USB-C cable - integrated - 30 cm

Features

Wake on LAN, Preboot Execution Environment (PXE) support, full duplex support, DisplayPort Alt Mode, 100W power delivery

Compliant Standards

FCC, RoHS, USB Battery Charging Specification Rev. 1.2, UASP (USB Attached SCSI Protocol), USB Power Delivery 3.0

System Requirements

OS Required

Google Chrome OS, Apple MacOS X 10.9 - 10.15, Apple macOS 11.0, Microsoft Windows 7 / 8 / 8.1 / 10 / 11, Apple macOS 12.0, Apple macOS 13.0

Manufacturer Warranty

Service & Support

Limited warranty - 3 years

Dimensions & Weight (Shipping)

Shipping Width

11 cm

Shipping Depth

5.9 cm

Shipping Height

1.4 cm

Shipping Weight

204 g

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

45 °C
