EAN / GTIN:
1210002605984
Device Type
Wi-Fi system - mesh - 3-port switch (integrated)
Wi-Fi System Components
Router
Connectivity Technology
Wireless, wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11be (Wi-Fi 7)
Frequency Band
2.4 GHz / 5 GHz / 6 GHz
Data Transfer Rate
9.3 Gbps
Performance
Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (5 GHz): 2880 Mbps ¦ Maximum data rate (6 GHz): 5760 Mbps ¦ Channel bandwidth: up to 320 MHz
Capacity
Connected devices: up to 200 ¦ Streams: 6
Network / Transport Protocol
PPTP, L2TP, IPSec, PPPoE, DHCP, DDNS, IPv4, IPv6, OpenVPN
Routing Protocol
IGMP, static IP routing
Remote Management Protocol
IPv4, IPv6
Encryption Algorithm
WPA3-Personal, WPA2-Personal, WPA-Personal
Features
Auto-sensing per device, IGMP snooping, IPS, parental control, Access Point operational mode, DDos attack prevention, QoS, DHCP server, port forwarding, reset button, SPIF, DHCP client, FOTA, IGMP proxy, router mode, Backhaul Technology, 2x2 MU-MIMO technology, VLAN Tagging, schedule reboot, OpenVPN server, IPTV support, WPS button, BSS Coloring, Guest Network, Address Reservation, Real-Time IoT Protection, Malicious Site Blocker, Home Network Scanner, 5G/4G router mode, AI-Driven Mesh, MLO
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11k, UPnP, IEEE 802.11ac, IEEE 802.11r, IEEE 802.11v, IEEE 802.11ax, IEEE 802.11be, Wi-Fi CERTIFIED 7, Plug and Play, FCC, RoHS
Line Coding Format
4096 QAM, OFDMA
Type
Wireless cellular modem
Mobile Communication Protocol
WCDMA, 5G NR, 4G LTE
Cellular Band
LTE B3, LTE B7, LTE B20, LTE B1, LTE B5, LTE B28, LTE B8, LTE B40, LTE B41, LTE B32, LTE B43, 5G n78, 5G n1, 5G n3, 5G n5, 5G n7, 5G n8, 5G n20, 5G n28, 5G n40, 5G n41, 5G n77, 5G n38, WCDMA B1, WCDMA B5, WCDMA B8, 5G n75, 5G n76
Max Transfer Rate
3.4 Gbps
Internet of Things (IoT) Compatible
Yes
Communications Type
Cloud
Communications Technology
Wi-Fi
Intelligent Assistant
Google Assistant, Alexa
Voice Controlled
Indirect
Interfaces
WAN / LAN: 3 x 2.5GBase-T - RJ-45 ¦ USB 3.0: 1 x 9 pin USB Type A ¦ Antenna: 2 x SMA
Expansion Slots
1 (total) / 1 (free) x Nano-SIM
Power Device
External power adapter
Cables Included
1 x network cable
Service & Support
Limited warranty - 3 years
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% RH
