ViewSonic CDE7530 CDE30 Series - 75" LED-backlit L

Images Manuals

Images for illustrative purposes

ViewSonic CDE7530 CDE30 Series

View all VIEWSONIC Digital Signage | Large Displays - Visit the VIEWSONIC Store (CDE7530) - (ECE7805261)

CDE7530 - 75" Diagonal Class CDE30 Series LED-backlit LCD display - digital signage - with built-in SoC media player - 4K UHD (2160p) 3840 x 2160 - Direct LED

Connection made efficient
Wireless content sharing
Non-stop operation hours
SoC-powered performance
Corporate communication simplified
Insight report and remote desktop
View More
Compatible with creston, AMX, extron

FREE Delivery on orders over €250

12 Available to Ship
Order within 15Hrs 13Mins for: FREE Delivery (8 Jun or 9 Jun)

€2285.93 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

With stunning 4K Ultra HD resolution, high brightness, and landscape and portrait modes, the CDE30 Series offers continuous and sustainable 24/7 display for both corporate and campus communication. Purpose-engineered for ease of use, the display is equipped with a Quad Core SoC to run multiple operations seamlessly, and its USB-C one-cable solution sorts for effortless connection with external devices. Designed for easy-to-operate continuous multimedia playback, the CDE30 Series offers cable-free screen casting and screen sharing through myViewBoard Display and ViewBoard Cast, which also supports Airplay and Chromecast. Remote management via the intuitive myViewBoard Manager makes changing content, broadcasting, and software updates a breeze. Complete with daisy-chain compatibility, the CDE30 Series meets and exceeds the communication needs of any campus or corporate spaces.

Specification Summary

Product Description

ViewSonic CDE7530 CDE30 Series - 75" LED-backlit LCD display - 4K - for digital signage

Product Type

LED-backlit LCD flat panel display with built-in SoC media player

Energy Label QR Code URL

Https://eprel.ec.europa.eu/qr/2309660

Diagonal Class

75"

Commercial Use

Yes - digital signage

Resolution

3840 x 2160

Display Format

4K UHD (2160p)

Input Video Formats

480p, 720p, 1080i, 1080p, 480i, 576i, 576p, 4K

Frame Rate & Enhancement Technology

60 Hz Refresh Rate

Video Interface

HDMI

HDMI Ports Qty

3 ports

Connectivity

LAN

PC Interface

Serial RS-232, USB-C

Technology

ADS

LCD Backlight Technology

Direct LED

Image Aspect Ratio

16:9

TV Tuner

No tuner

Picture Enhancements

Blue Light Filter

Speaker System

2 speakers

Storage Capacity

32 GB

USB

3 ports

Included Accessories

Remote control, remote control, batteries, ViewBoard software, screws, RS232 adapter

Voltage

AC 100-240 V (50 - 60 Hz)

Energy Class

Class G

Power Consumption Operational

126 Watt

Power Consumption (On mode)

232 W

Dimensions (WxDxH) - without stand

1.6856 m x 8.16 cm x 96.37 cm

Weight

34.65 kg

Environmental Standards

ENERGY STAR Qualified

Manufacturer Warranty

5-year warranty

Specifications

EAN / GTIN:

766907017496

General

Product Type

LED-backlit LCD flat panel display

Energy Label QR Code URL

Https://eprel.ec.europa.eu/qr/2309660

Energy Class

Class G

Power Consumption Operational

126 Watt

Power Consumption (On mode)

232 W

Power Consumption SDR (On mode)

232 kWh/1000h

Diagonal Class

75"

Commercial Use

Yes - digital signage

Combined With

Built-in SoC media player

Series

CDE30 Series

Operating System

Android OS 11

TV Tuner

No tuner

TV Tuner Presence

Video Interface

HDMI

HDMI Ports Qty

3 ports

PC Interface

Serial RS-232, USB-C

Modes

Portrait mode, landscape mode

Picture Enhancements

Blue Light Filter

Design

Sleek Design

Dimensions

Without stand

Width

1.6856 m

Depth

8.16 cm

Height

96.37 cm

Weight

34.65 kg

Display

LCD Display Technology

ADS

Colour Support

1070000000 colours

Resolution

3840 x 2160

Display Format

4K UHD (2160p)

Image Aspect Ratio

16:9

Frame Rate & Enhancement Technology

60 Hz Refresh Rate

LCD Backlight Technology

Direct LED

Coating

Anti-glare, 3H Hard, 25% haze

Image Contrast Ratio

1200:1

Dynamic Contrast Ratio

5000:1

Brightness

500 cd/m²

Viewing Angle

178 degrees

Viewing Angle (Vertical)

178 degrees

Response Time

8 ms

Backlight Life

50,000 hour(s)

Operation Hours / Days

24 / 7

Features

Dimming Control (DCR), Open Pluggable Specification slot, Crestron Connected Compatible, Flicker free technology, OPS Slot, ViewBoard Cast software, WiFi slot, 1.07 billion colours (8-bit+FRC), blue light reduction

Stands & Mounts

Stand

Optional

Flat Panel Mount Interface

800 x 600 mm

VESA Compatibility

Yes

Video Features

Input Video Formats

480p, 720p, 1080i, 1080p, 480i, 576i, 576p, 4K

Media Player

Supported Video Formats

MPEG-1, MPEG-2, MPEG-4, Xvid, WMV, ASF, AVI, MKV, MOV, VOB, FLV, RM, TS, H.264, RMVB, DAT, TP, TRP, WebM, MPG, MPEG, OGM, 3GP

Supported Audio Formats

MP3, WMA, WAV, AC3, AAC, M4A, MP4

Supported Pictures Formats

BMP, PNG, JPEG

USB Port

Yes

USB Ports Qty

Configuration

ARM Cortex-A55 Quad-Core - 4 GB - 32 GB

Remote Control

Type

Remote control

Battery Form Factor

AAA type

Battery Included

Yes

Battery Included Qty

Battery Required Qty

Audio System

Speaker System

2 speakers

Output Power / Total

16 Watt

Features

Audio Return Channel (ARC)

Speakers

2 x main channel speaker - 10 Watt

Network & Internet Multimedia

Connectivity

LAN

LAN Protocol

Fast Ethernet

Connections

Connector Type

3 x HDMI input ¦ RS-232 input ¦ HDMI output ¦ USB-C with 65W Power Delivery ¦ SPDIF output ¦ LAN ¦ USB 2.0 ¦ USB 3.0

Miscellaneous

Included Accessories

Remote control, batteries, ViewBoard software, screws, RS232 adapter

Cables Included

HDMI cable - 3 m ¦ USB-C cable - 1.8 m

Compliant Standards

CB, FCC, RoHS, WEEE, cTUVus, REACH, UkrSEPRO, ERP, EAC, RCM, CE/EMC, HDCP 2.2, Mexico Energy label, TPCH, Mexico NOM, SCIP, Annex II (EU) 2015/863, ICES 003, Green BOM

Sustainability Information

ENERGY STAR Certified

Yes

ENERGY STAR Version

8.0

Power

Power Device

Power supply

Input Voltage

AC 100-240 V (50 - 60 Hz)

Power Consumption (Off Mode)

0.5 Watt
