Overview

Range/Series Overview


IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

Streamline your presentations, enhance collaboration, and succeed with the ViewSonic CDE5530 digital display. Whether your employees are in office or working remotely, they will enjoy fast and easy ways to communicate thanks to ViewBoard Cast screen sharing software and the myViewBoard Display app that allows up to four participants to connect and share content. For maximum visibility even in rooms with high ambient light, these displays offer stunning 4K Ultra HD resolution, high brightness and a 25% high haze anti-glare screen. What's more, these all-in-one displays simplify installation and maintenance thanks to a powerful secured embedded platform that delivers smooth content playback without the need for a PC or media player.


Specification Summary

Product Description
ViewSonic CDE5530 CDE30 Series - 55" LED-backlit LCD display - 4K - for digital signage
Product Type
LED-backlit LCD flat panel display with built-in SoC media player
Energy Label QR Code URL
Https://eprel.ec.europa.eu/qr/2309647
Diagonal Class
55"
Commercial Use
Yes - digital signage
Platform
Android
Resolution
3840 x 2160
Display Format
4K UHD (2160p)
Video Interface
HDMI
HDMI Ports Qty
2 ports
Connectivity
LAN
PC Interface
Serial RS-232, USB-C
Technology
VA
LCD Backlight Technology
Direct-lit LED
Image Aspect Ratio
16:9
TV Tuner
No tuner
Picture Enhancements
Blue Light Filter
Speaker System
2 speakers
Storage Capacity
32 GB
USB
3 ports
Included Accessories
Remote control, remote control, batteries, screws, RS232 adapter
Voltage
AC 100-240 V (50 - 60 Hz)
Energy Class
Class G
Power Consumption Operational
82 Watt
Dimensions (WxDxH) - without stand
123.3 cm x 7.15 cm x 70.35 cm
Weight
13.4 kg
Environmental Standards
ENERGY STAR Qualified
Manufacturer Warranty
5-year warranty

Specifications

EAN / GTIN:
766907017472
General
Product Type
LED-backlit LCD flat panel display
Energy Label QR Code URL
Https://eprel.ec.europa.eu/qr/2309647
Energy Class
Class G
Power Consumption Operational
82 Watt
Power Consumption SDR (On mode)
143 kWh/1000h
Diagonal Class
55"
Commercial Use
Yes - digital signage
Combined With
Built-in SoC media player
Series
CDE30 Series
Platform
Android
Operating System
Android OS 11
TV Tuner
No tuner
TV Tuner Presence
No
Video Interface
HDMI
HDMI Ports Qty
2 ports
PC Interface
Serial RS-232, USB-C
Modes
Portrait mode, landscape mode
Picture Enhancements
Blue Light Filter
Dimensions
Without stand
Width
123.3 cm
Depth
7.15 cm
Height
70.35 cm
Weight
13.4 kg
Display
LCD Display Technology
VA
Colour Support
1070000000 colours
Resolution
3840 x 2160
Display Format
4K UHD (2160p)
Image Aspect Ratio
16:9
LCD Backlight Technology
Direct-lit LED
Coating
Anti-glare, 3H Hard, 25% haze
Image Contrast Ratio
1200:1
Dynamic Contrast Ratio
5000:1
Brightness
500 cd/m²
Viewing Angle
178 degrees
Viewing Angle (Vertical)
178 degrees
Response Time
6.5 ms
Backlight Life
50,000 hour(s)
Operation Hours / Days
24 / 7
Features
Dimming Control (DCR), Crestron Connected Compatible, Flicker free technology, WiFi slot, 1.07 billion colours (8-bit+FRC), blue light reduction, 24/7 operation time
Stands & Mounts
Flat Panel Mount Interface
400 x 200 mm
VESA Compatibility
Yes
Media Player
Supported Video Formats
MPEG-1, MPEG-2, MPEG-4, Xvid, WMV, ASF, AVI, MKV, MOV, VOB, FLV, RM, TS, H.264, RMVB, DAT, TP, TRP, WebM, MPG, MPEG, OGM, 3GP
Supported Audio Formats
MP3, WMA, WAV, AC3, AAC, M4A, MP4
Supported Pictures Formats
BMP, PNG, JPEG
USB Port
Yes
USB Ports Qty
3
Configuration
ARM Cortex-A55 Quad-Core - 4 GB - 32 GB
Remote Control
Type
Remote control
Battery Form Factor
AAA type
Battery Included
Yes
Battery Included Qty
2
Battery Required Qty
2
Audio System
Speaker System
2 speakers
Output Power / Total
32 Watt
Features
Audio Return Channel (ARC), Apple AirPlay support
Speakers
2 x main channel speaker - 16 Watt
Network & Internet Multimedia
Connectivity
LAN
LAN Protocol
Fast Ethernet
Connections
Connector Type
2 x HDMI input ¦ RS-232 input ¦ HDMI output ¦ USB-C with 65W Power Delivery ¦ SPDIF output ¦ LAN ¦ USB 2.0 ¦ USB 3.0
Miscellaneous
Included Accessories
Remote control, batteries, screws, RS232 adapter
Cables Included
HDMI cable - 3 m ¦ USB-C cable - 1.8 m
Compliant Standards
ICES-003, CB, FCC, RoHS, WEEE, cTUVus, REACH, UkrSEPRO, ERP, EAC, RCM, Mexico Energy label, TPCH, Mexico NOM, SCIP, Annex II (EU) 2015/863, Green BOM
Sustainability Information
ENERGY STAR Certified
Yes
ENERGY STAR Version
8.0
Power
Power Device
Power supply
Input Voltage
AC 100-240 V (50 - 60 Hz)
Power Consumption (Off Mode)
0.5 Watt
On / Off Switch
Yes
Manufacturer Warranty
Service & Support
Limited warranty - replace or repair - 5 years - on-site
Dimensions & Weight (Shipping)
Width (Shipping)
133.2 cm
Depth (Shipping)
15.6 cm
Height (Shipping)
81.9 cm
Weight (Shipping)
19.5 kg
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
20 - 80% (non-condensing)
