Cisco Catalyst 9200L - Network Advantage - switch

Images Manuals

Images for illustrative purposes

Cisco Catalyst 9200L

Name: Cisco Catalyst 9200L
Brand: CISCO
SKU: ECE5086108
Price: 3476.66 EUR
Availability: OutOfStock

View all CISCO Network Switches - Visit the CISCO Store (C9200L-24T-4X-A) - (ECE5086108)

Model: Cisco Catalyst

Catalyst 9200L - Network Advantage - switch - L3 - 24 x 10/100/1000 + 4 x 10 Gigabit SFP+ (uplink) - rack-mountable

CONFIGURATION
IT SIMPLIFIED
SECURE
ALWAYS-ON
MANAGEMENT

FREE Delivery on orders over €250

0 Available to Ship
Restock 25-Jun-2026 Estimated, Out of Stock Prices are Estimated.

RRP ~~€5215.13~~

€3476.66 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The Cisco Catalyst 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise – it is secure, always on, and IT SIMPLIFIED.

Specification Summary

Product Description

Cisco Catalyst 9200L - Network Advantage - switch - 24 ports - rack-mountable

Device Type

Switch - 24 ports - L3 - stackable

Enclosure Type

Rack-mountable

Subtype

Gigabit Ethernet

Ports

24 x 10/100/1000 + 4 x 10 Gigabit SFP+ (uplink)

Performance

Stacking bandwidth: 80 Gbps ¦ Switching capacity: 128 Gbps ¦ Forwarding rate: 190.4 Mpps

Capacity

Virtual networks: 1 ¦ IPv4 routes: 11000 ¦ IPv4 routing table entries: 3000 ¦ IPv6 routing table entries: 1500 ¦ Multicast scale: 1000 ¦ ACL scale entries: 1500 ¦ FNF entries: 16000 ¦ VLANs supported: 1024 ¦ Switched virtual interfaces (SVIs): 512 ¦ QoS hardware queues per port: 8

MAC Address Table Size

16000 entries

Jumbo Frame Support

9198 bytes

Routing Protocol

OSPF, IS-IS, RIP-1, RIP-2, EIGRP, HSRP, VRRP, PIM-SM, EIGRP for IPv6, PIM-SSM, MSDP, policy-based routing (PBR), RIPng, MSTP

Remote Management Protocol

SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF

Features

QoS, Cisco StackWise Technology, Rapid PVST+, SRR, PXE support, RSPAN, NetFlow, Energy Efficient Ethernet, MIB, CoS, FNF, 802.1x authentication, DSCP support, MACsec support, 6MB packet buffer, CoPP, SPAN, EEM, PIM, FHS, PVLAN support, CIR

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3bz

Power

AC 100-240 V (50 - 60 Hz)

Power Redundancy

Optional

Dimensions (WxDxH)

44.5 cm x 4.4 cm x 28.8 cm

Weight

5 kg

Manufacturer Warranty

Limited lifetime warranty

Specifications

EAN / GTIN:

889728170253

General

Device Type

Switch - 24 ports - L3 - stackable

Enclosure Type

Rack-mountable

Subtype

Gigabit Ethernet

Ports

24 x 10/100/1000 + 4 x 10 Gigabit SFP+ (uplink)

Performance

Stacking bandwidth: 80 Gbps ¦ Switching capacity: 128 Gbps ¦ Forwarding rate: 190.4 Mpps

Capacity

MAC Address Table Size

16000 entries

Jumbo Frame Support

9198 bytes

Routing Protocol

OSPF, IS-IS, RIP-1, RIP-2, EIGRP, HSRP, VRRP, PIM-SM, EIGRP for IPv6, PIM-SSM, MSDP, policy-based routing (PBR), RIPng, MSTP

Remote Management Protocol

SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF

Features

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3bz

RAM

2 GB

Flash Memory

4 GB

Expansion / Connectivity

Interfaces

24 x 1000Base-T RJ-45 ¦ 4 x 10GBase-X SFP+ uplink ¦ 1 x network stack device ¦ 1 x management (LAN) RJ-45 ¦ 1 x console RJ-45

Power

Power Device

Internal power supply - hot-plug

Max Supported Qty

Power Redundancy

Optional

Voltage Required

AC 100-240 V (50 - 60 Hz)

Miscellaneous

MTBF

525,990 hours

Compliant Standards

CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, FCC CFR47 Part 15 B Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35

Dimensions & Weight

Width

44.5 cm

Depth

4.4 cm

Height

28.8 cm

Weight

5 kg

Manufacturer Warranty

Service & Support

Limited warranty - advance parts replacement - lifetime - response time: next business day

Environmental Parameters

Humidity Range Operating

5 - 90% (non-condensing)

Min Storage Temperature

-40 °C

Max Storage Temperature

70 °C

Humidity Range Storage

5 - 90% (non-condensing)
