Cisco Catalyst 9200 - Network Essentials - switch

Images Manuals

Images for illustrative purposes

Cisco Catalyst 9200

Name: Cisco Catalyst 9200
Brand: CISCO
SKU: ECE5667475
Price: 5849.74 EUR
Availability: OutOfStock

View all CISCO Network Switches - Visit the CISCO Store (C9200-48PXG-E) - (ECE5667475)

Model: Cisco Catalyst

Catalyst 9200 - Network Essentials - switch - L3 - smart - 40 x 10/100/1000 (PoE+) + 8 x 100/1000/2.5G/5G/10GBase-T - rack-mountable - PoE+ (740 W)

CONFIGURATION
IT SIMPLIFIED
SECURE
ALWAYS-ON
MANAGEMENT

FREE Delivery on orders over €250

0 Available to Ship
Restock 25-Jun-2026 Estimated, Out of Stock Prices are Estimated.

RRP ~~€7884.78~~

€5849.74 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The Cisco Catalyst 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise – it is secure, always on, and IT SIMPLIFIED.

Specification Summary

Product Description

Cisco Catalyst 9200 - Network Essentials - switch - 48 ports - smart - rack-mountable

Device Type

Switch - 48 ports - L3 - smart - stackable

Enclosure Type

Rack-mountable

Subtype

Gigabit Ethernet

Ports

40 x 10/100/1000 (PoE+) + 8 x 100/1000/2.5G/5G/10GBase-T

Power Over Ethernet (PoE)

PoE+

PoE Budget

740 W

Performance

Stacking bandwidth: 160 Gbps ¦ Switching bandwidth: 400 Gbps ¦ Switching capacity with stacking: 580 Gbps ¦ Forwarding rate: 297.61 Mpps ¦ Forwarding rate with stacking: 431 Mpps

Capacity

QoS scale entries: 1000 ¦ ACL scale entries: 1600 ¦ IPv4 routing table entries: 4000 ¦ IPv6 routing table entries: 2000 ¦ Packet buffer size: 6 MB ¦ VLAN IDs: 4096 ¦ Switched virtual interfaces (SVIs): 1000 ¦ Flexible NetFlow entries: 16000

MAC Address Table Size

32000 entries

Jumbo Frame Support

9198 bytes

Routing Protocol

OSPF, RIP, IS-IS, RIP-1, RIP-2, EIGRP, HSRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, MSDP, policy-based routing (PBR), RIPng, MSTP

Remote Management Protocol

SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF

Features

ARP support, STP support, QoS, Rapid PVST+, SRR, PXE support, RSPAN, Energy Efficient Ethernet, MIB, CoS, FNF, Cisco StackWise-160 technology, DSCP support, MACsec support, CoPP, SPAN, EEM, PIM, FHS, PVLAN support, CIR

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at, IEEE 802.3bz

Power

AC 100-240 V (50 - 60 Hz)

Power Redundancy

Optional

Dimensions (WxDxH)

44.4 cm x 39 cm x 4.4 cm

Weight

5.44 kg

Manufacturer Warranty

Limited lifetime warranty

Specifications

EAN / GTIN:

889728168274

General

Device Type

Switch - 48 ports - L3 - smart - stackable

Enclosure Type

Rack-mountable

Subtype

Gigabit Ethernet

Ports

40 x 10/100/1000 (PoE+) + 8 x 100/1000/2.5G/5G/10GBase-T

Power Over Ethernet (PoE)

PoE+

PoE Budget

740 W

Performance

Stacking bandwidth: 160 Gbps ¦ Switching bandwidth: 400 Gbps ¦ Switching capacity with stacking: 580 Gbps ¦ Forwarding rate: 297.61 Mpps ¦ Forwarding rate with stacking: 431 Mpps

Capacity

MAC Address Table Size

32000 entries

Jumbo Frame Support

9198 bytes

Routing Protocol

OSPF, RIP, IS-IS, RIP-1, RIP-2, EIGRP, HSRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, MSDP, policy-based routing (PBR), RIPng, MSTP

Remote Management Protocol

SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF

Encryption Algorithm

128-bit AES

Features

Compliant Standards

RAM

4 GB

Flash Memory

4 GB

Built-in Devices

RFID tag

Expansion / Connectivity

Interfaces

40 x 10/100/1000 Base-T RJ-45 PoE+ - 30 W ¦ 8 x 100/1000/2.5G/5G/10GBase-T RJ-45 ¦ 1 x management (LAN) RJ-45 ¦ 1 x console RJ-45 ¦ 1 x network stack device

Expansion Slots

1 (total) / 1 (free) x Expansion Slot

Power

Power Device

Internal power supply - hot-plug

Max Supported Qty

Power Redundancy

Optional

Power Provided

1000 watt

Voltage Required

AC 100-240 V (50 - 60 Hz)

Miscellaneous

MTBF

320,440 hours

Compliant Standards

CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, FCC CFR47 Part 15 B Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35

Dimensions & Weight

Width

44.4 cm

Depth

39 cm

Height

4.4 cm

Weight

5.44 kg

Manufacturer Warranty

Service & Support

Limited warranty - advance parts replacement - lifetime - response time: next business day ¦ Technical support - phone consulting - 90 days

Environmental Parameters

Min Operating Temperature

-5 °C

Max Operating Temperature

45 °C

Humidity Range Operating

5 - 90% (non-condensing)

Min Storage Temperature

-40 °C

Max Storage Temperature

70 °C

Humidity Range Storage

5 - 90% (non-condensing)
