Cisco Catalyst 9200 - Network Essentials - switch

Images Manuals

Images for illustrative purposes

Cisco Catalyst 9200

Name: Cisco Catalyst 9200
Brand: CISCO
SKU: ECE5751623
Price: 5869.74 EUR
Availability: OutOfStock

View all CISCO Network Switches - Visit the CISCO Store (C9200-24PXG-E) - (ECE5751623)

Model: Cisco Catalyst

Catalyst 9200 - Network Essentials - switch - L3 - Managed - 8 x 100/1000/2.5G/5G/10GBase-T + 16 x 10/100/1000 (PoE+) - rack-mountable - PoE+ (370 W)

CONFIGURATION
IT SIMPLIFIED
SECURE
ALWAYS-ON
MANAGEMENT

FREE Delivery on orders over €250

0 Available to Ship
Restock 25-Jun-2026 Estimated, Out of Stock Prices are Estimated.

RRP ~~€8812.10~~

€5869.74 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The Cisco Catalyst 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise – it is secure, always on, and IT SIMPLIFIED.

Features Summary

CONFIGURATION
8 x 1/2.5/5/10G Ethernet with PoE+, 16 x 10/100/1000M Ethernet with PoE+, 370W total PoE budget
IT SIMPLIFIED
Catalyst 9200 Series switches simplify complexity, optimize IT, and reduce operational costs with Cisco UADP ASIC and Cisco IOS XE providing consistency, intelligence and automation
SECURE
Enhanced security with MACsec encryption, full flexible NetFlow, and trustworthy solutions that protect the integrity of the hardware as well as the software and all data that flows through the switch
ALWAYS-ON
Differentiated resiliency with Field-Replaceable Units (FRU) and redundant power supplies and fans, modular uplinks, 160 Gbps backplane stacking and layer 3 support
MANAGEMENT
Choice of CLI, Cisco Catalyst Center (formerly Cisco DNA Center) on-premises management, or cloud monitoring for Catalyst on Meraki dashboard

Specification Summary

Product Description

Cisco Catalyst 9200 - Network Essentials - switch - 24 ports - Managed - rack-mountable

Device Type

Switch - 24 ports - L3 - Managed - stackable

Enclosure Type

Rack-mountable

Subtype

Gigabit Ethernet

Ports

8 x 100/1000/2.5G/5G/10GBase-T + 16 x 10/100/1000 (PoE+)

Power Over Ethernet (PoE)

PoE+

PoE Budget

370 W

Performance

Stacking bandwidth: 80 Gbps ¦ Switching capacity: 272 Gbps ¦ Switching capacity with stacking: 352 Gbps ¦ Forwarding rate: 214.28 Mpps

Capacity

Virtual networks: 1 ¦ IPv4 routes: 11000 ¦ IPv4 routing table entries: 3000 ¦ IPv6 routing table entries: 1500 ¦ Multicast scale: 1000 ¦ ACL scale entries: 1500 ¦ FNF entries: 16000 ¦ VLANs supported: 1024 ¦ Switched virtual interfaces (SVIs): 512 ¦ QoS hardware queues per port: 8 ¦ Packet buffer size: 6 MB

MAC Address Table Size

16000 entries

Jumbo Frame Support

9198 bytes

Routing Protocol

OSPF, RIP, IS-IS, RIP-1, RIP-2, EIGRP, HSRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, MSDP, policy-based routing (PBR), RIPng, MSTP

Remote Management Protocol

SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF, IPv4, IPv6, YANG

Features

ARP support, STP support, QoS, Rapid PVST+, SRR, PXE support, RSPAN, Energy Efficient Ethernet, MIB, VRF, CoS, FNF, DSCP support, MACsec support, CoPP, VXLAN, LISP, SPAN, SGT caching, EEM, PIM, FHS, PVLAN support, CIR, Cisco StackWise-80 technology

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3bz

Power

AC 100-240 V (50 - 60 Hz)

Power Redundancy

Optional

Dimensions (WxDxH)

44.5 cm x 4.4 cm x 35 cm

Weight

5.44 kg

Manufacturer Warranty

Limited lifetime warranty

Specifications

EAN / GTIN:

889728168267

General

Device Type

Switch - 24 ports - L3 - Managed - stackable

Enclosure Type

Rack-mountable

Subtype

Gigabit Ethernet

Ports

8 x 100/1000/2.5G/5G/10GBase-T + 16 x 10/100/1000 (PoE+)

Power Over Ethernet (PoE)

PoE+

PoE Budget

370 W

Performance

Stacking bandwidth: 80 Gbps ¦ Switching capacity: 272 Gbps ¦ Switching capacity with stacking: 352 Gbps ¦ Forwarding rate: 214.28 Mpps

Capacity

MAC Address Table Size

16000 entries

Jumbo Frame Support

9198 bytes

Routing Protocol

OSPF, RIP, IS-IS, RIP-1, RIP-2, EIGRP, HSRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, MSDP, policy-based routing (PBR), RIPng, MSTP

Remote Management Protocol

SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF, IPv4, IPv6, YANG

Encryption Algorithm

128-bit AES

Features

Compliant Standards

RAM

2 GB

Flash Memory

4 GB

Expansion / Connectivity

Interfaces

8 x 100/1000/2.5G/5G/10GBase-T RJ-45 ¦ 16 x 1000Base-T RJ-45 PoE+ ¦ 1 x network stack device ¦ 1 x management (LAN) RJ-45 ¦ 1 x console RJ-45

Power

Power Device

Internal power supply - hot-plug

Max Supported Qty

Power Redundancy

Optional

Voltage Required

AC 100-240 V (50 - 60 Hz)

Miscellaneous

MTBF

379,410 hours

Compliant Standards

CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, FCC CFR47 Part 15 B Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35

Dimensions & Weight

Width

44.5 cm

Depth

4.4 cm

Height

35 cm

Weight

5.44 kg

Manufacturer Warranty

Service & Support

Limited warranty - replacement - lifetime - response time: next business day ¦ Technical support - consulting - 90 days

Environmental Parameters

Min Operating Temperature

-5 °C

Max Operating Temperature

45 °C

Humidity Range Operating

5 - 90% (non-condensing)

Min Storage Temperature

-40 °C

Max Storage Temperature

70 °C

Humidity Range Storage

5 - 90% (non-condensing)
