HPE StoreFabric SN1100E - host bus adapter - PCIe

Images Manuals

Images for illustrative purposes

HPE StoreFabric SN1100E

View all HPE PCI / M.2 Cards and Adapters - Visit the HPE Store (C8R38A) - (ECE2885631)

StoreFabric SN1100E - Host bus adapter - PCIe 3.0 x8 low profile - 16Gb Fibre Channel x 1 - for ProLiant DL360p Gen8, DL380p Gen8, DL385p Gen8, ML350p Gen8, XL230a Gen9, StoreEasy 3850

High-performance, Fibre Channel Host Bus Adapters
Outstanding Fibre Channel Host Bus Adapters for Virtualization
Four Ports for Additional Bandwidth

FREE Delivery on orders over €250

0 Available to Ship
Restock 01-Jul-2026 Estimated, Out of Stock Prices are Estimated.

€2399.75 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

Looking for a high-bandwidth HBA solution to meet the requirements of increasing server virtualization and consolidation? Finding it difficult to realize the full bandwidth potential of your server running I/O intensive applications? The HPE StoreFabric SN1100E 16Gb Host Bus Adapters deliver twice the I/O performance of 8 Gb HBAs, it takes storage networking performance and efficiency to the next level. They enable rapid storage and retrieval of critical information when using high bandwidth cloud applications and storage intensive applications such as backup, database transactions and rich media. Designed for increased virtual machine density and bandwidth requirements, the SN1100E 16Gb HBA products enable more applications and virtual machines to run on a single server and port, resulting in reduced cabling. The SN1100E 16Gb HBAs are backward compatible with 8 Gb and 4 Gb networks and will protect your current and future IT investments.

Specification Summary

Product Description

HPE StoreFabric SN1100E - host bus adapter - PCIe 3.0 x8 - 16Gb Fibre Channel x 1

Device Type

Host bus adapter

Form Factor

Plug-in card - low profile

Interface (Bus) Type

PCI Express 3.0 x8

Ports

16Gb Fibre Channel x 1

Dimensions (WxDxH)

3.5 cm x 23 cm x 13 cm

Cabling Type

Fibre optic

Data Link Protocol

16Gb Fibre Channel (SW)

Data Transfer Rate

14.025 Gbps

System Requirements

SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Microsoft Windows Server 2008 R2 x64 Edition, Microsoft Windows Server 2008 (32/64-bits), VMware ESXi, VMware ESX

Designed For

ProLiant DL160 Gen8, DL360e Gen8, DL360p Gen8, DL380e Gen8, DL380p Gen8, DL385p Gen8, DL560 Gen8, ML350p Gen8, SL230s Gen8, XL230a Gen9; StoreEasy 3850

Specifications

EAN / GTIN:

887758330852

General

Device Type

Host bus adapter

Form Factor

Plug-in card - low profile

Interface (Bus) Type

PCI Express 3.0 x8

Networking

Ports

16Gb Fibre Channel x 1

Connectivity Technology

Wired

Cabling Type

Fibre optic

Data Link Protocol

16Gb Fibre Channel (Short Wave)

Data Transfer Rate

14.025 Gbps

Features

Auto-negotiation

Expansion / Connectivity

Expansion Slots

1 (total) / 0 (free) x SFP+

Interfaces

1 x 16Gb Fibre Channel (Short Wave) - LC multi-mode

Miscellaneous

Included Accessories

Low-profile bracket, full-height bracket, 16Gb SFP+

Software / System Requirements

OS Required

SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Microsoft Windows Server 2008 R2 x64 Edition, Microsoft Windows Server 2008 (32/64-bits), VMware ESXi, VMware ESX

Dimensions & Weight

Width

3.5 cm

Depth

23 cm

Height

13 cm

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

45 °C

Humidity Range Operating

15 - 80% (non-condensing)

Compatibility Information

Designed For

HPE ProLiant DL160 Gen8, DL160 Gen8 Base, DL160 Gen8 Entry, DL160 Gen8 Performance, DL360e Gen8, DL360e Gen8 Base, DL360e Gen8 Entry, DL360e Gen8 Performance, DL360e Gen8 Special Server, DL360p Gen8, DL360p Gen8 Base, DL360p Gen8 CMS, DL360p Gen8 Entry, DL360p Gen8 High Performance, DL360p Gen8 Performance, DL380e Gen8, DL380e Gen8 Base, DL380e Gen8 Entry, DL380e Gen8 High Performance, DL380e Gen8 Storage, DL380p Gen8, DL380p Gen8 Base, DL380p Gen8 Entry, DL380p Gen8 High Performance, DL380p Gen8 Performance, DL380p Gen8 Special, DL385p Gen8, DL385p Gen8 Dedicated Workload, DL385p Gen8 Entry, DL385p Gen8 Maximized Consolidation, DL385p Gen8 Storage, DL385p Gen8 Storage Centric, DL560 Gen8, DL560 Gen8 Base, DL560 Gen8 Entry, DL560 Gen8 Performance, ML350p Gen8, ML350p Gen8 Base, ML350p Gen8 Entry, ML350p Gen8 Performance, ML350p Gen8 Special Server, SL230s Gen8 1U Left Half Width Tray, SL230s Gen8 1U Right Half Width Tray, SL230s Gen8 Base 1U Left Tray Server, SL230s Gen8 Base 1U Right Tray Server, XL230a Gen9 Compute Tray, XL230a Gen9 Compute Tray (12G), XL230a Gen9 Compute Tray (6G) ¦ HPE StoreEasy 3850 Gateway Single Node
