Overview

Range/Series Overview


IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

This product is part of the Back-UPS range. The BK550EI features a total of 6 power outlets, 3 of which are UPS battery backup and 3 that are surge only. Its runtime at 100W is 24 minutes 20 seconds It provides data line protection with a RJ45 analog phone line for phone or fax or modem or DSL. Its dimensions are 16.5 x 9.1 x 28.4 cm and 6.32kg. The BK550EI ensures office systems and their valuable data are protected from dangerous power surges, spikes and blackouts.


Features Summary

  • Serial connectivity
    Use any Home Automation network to monitor and control the S20 through its RS-232 serial port. For information on how to communicate with the S20, see APC's Application Note #102. Crestron and AMX installers should visit their respective websites for information on how to integrate the S20 into those networks.
  • Serial connectivity
    Provides management of the UPS via a serial port.
  • USB connectivity
    Provides management of the UPS via a USB port (not available on all models).

Specification Summary

Product Description
APC Back-UPS CS 500 - UPS - 300 watt - 500 VA
Device Type
UPS - external
Weight
6 kg
Load Rating
Individual PC
Input Voltage
AC 230 V
Output Voltage
AC 230 V ± 8%
Power Capacity
300 watt / 500 VA
Input Connectors
1 x power IEC 60320 C14
Output connectors
1 x power IEC 60320 C13 (surge) ¦ 3 x power IEC 60320 C13 (UPS and surge)
Battery
Lead Acid
Battery Form Factor
Internal
Batteries Qty
1
Run Time (Up To)
2.4 min at full load
Networking
RS-232, USB
Colour
Beige
System Requirements
Apple MacOS 9, Apple MacOS 9.0.4 or later, Microsoft Windows 98/ME/2000/XP
Dimensions (WxDxH)
9.1 cm x 28.4 cm x 16.5 cm
Manufacturer Warranty
2-year warranty

Specifications

EAN / GTIN:
731304016359
General
Device Type
UPS - external
Battery Enclosure Type
Internal
Colour
Beige
Power Device
Load Rating
Individual PC
UPS Technology
Off-line
Input Voltage
AC 230 V
Input Voltage Range
AC 196 - 280 V
Input Voltage Range (Adjustable)
AC 160 - 300 V
Input Voltage Margin
± 5%
Frequency Required
50/60 Hz
Input Connectors
1 x power IEC 60320 C14
Power Output Connectors Details
1 x power IEC 60320 C13 (surge) ¦ 3 x power IEC 60320 C13 (UPS and surge)
Output Voltage
AC 230 V ± 8%
Power Capacity
300 watt / 500 VA
Dataline Surge Protection
Phone line - RJ-11
Output Waveform
Stepped approximation to a sinewave
Surge Suppression
Yes
Surge Energy Rating
300 joules
Circuit Protection
Circuit breaker
Battery
Quantity
1
Technology
Lead Acid
Run Time (Up To)
2.4 min at full load
Recharge Time
8 hours
Networking
Remote Management Interface
RS-232, USB
Expansion / Connectivity
Interfaces
1 x management (RS-232/USB) - RJ-45
Miscellaneous
Cables Included
USB cable - external
Equipment Protection Value
100000 Euros
Features
LED display, audible alarm
Compliant Standards
C-Tick, GOST, UL 1449, VDE, EN 50091-2, EN 50091-1
Software / System Requirements
Software Included
APC PowerChute Personal Edition
OS Required
Apple MacOS 9, Apple MacOS 9.0.4 or later, Microsoft Windows 98/ME/2000/XP
Manufacturer Warranty
Service & Support
Limited warranty - replace or repair - 2 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Min Storage Temperature
-15 °C
Max Storage Temperature
45 °C
Humidity Range Operating
0 - 95%
Humidity Range Storage
0 - 95%
Sound Emission
40 dBA
Dimensions & Weight
Width
9.1 cm
Depth
28.4 cm
Height
16.5 cm
Weight
6 kg
Dimensions & Weight (Shipping)
Shipping Width
24.1 cm
Shipping Depth
36.8 cm
Shipping Height
17.8 cm
Shipping Weight
7.1 kg
