Device Type
UPS - wall mountable / surface mountable
Localisation
United Kingdom
Input Voltage Range
AC 180 - 266 V
Frequency Provided
50/60 Hz ± 1Hz
Frequency Required
47 - 63 Hz
Input Connectors
1 x power BS 1363A
Power Output Connectors Details
6 x power BS 1363A (UPS) ¦ 2 x power BS 1363A (UPS and surge) ¦ 1 x 4 pin USB Type A 2.4 A ¦ 1 x 24 pin USB-C
Output Voltage
AC 230 V ± 8% - 50/60 Hz
Max Electric Current
5.7 A
Power Capacity
600 Watt / 1050 VA
Dataline Surge Protection
Ethernet 10/100Base-TX - RJ-45
Output Waveform
Stepped approximation to a sinewave
Surge Energy Rating
310 Joules
Circuit Protection
Circuit breaker
Efficiency
80% at 100% Load
Run Time (Up To)
1.49 min at 600 Watts ¦ 11 min at 240 Watts ¦ 28 min at 119 Watts ¦ 92 min at 40 Watts
Cables Included
Power cable - integrated
Equipment Protection Value
100000 Euros
Features
User-replaceable batteries, LED indicators, audible alarm
Compliant Standards
EAC, EN 62040-2:2006+AC:2006, EN IEC 62040-1:2019 + A11:2021, EN/IEC 62040-2:2018, EU RoHS, REACH, China RoHS, IP20
Service & Support
Limited warranty - replace or repair - 2 years
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
0 - 90% RH
