Product Form Factor
Rack-mountable - 2U
Built-in Devices
6 x hot-swap fans, 2 x rear fans
Sensors
Temperature sensor, voltage sensor
Front Accessible Bays Qty
8
CPU Upgradability
Upgradable
Motherboard Name
Tyan S8261GM2NE-2T
Installed Size
6144 GB (max)
Effective Memory Speed
6000 MHz
Rated Memory Speed
6000 MHz
Slots
24 (Total) / 24 (empty)
Interface Type
PCI Express (NVMe) / U.2
Graphics Processor
ASPEED AST2600
Ethernet Ports
2 x 10 Gigabit Ethernet, 1 x Gigabit Ethernet
Ethernet Controller
Intel X550-AT2, Realtek RTL8211F
Data Link Protocol
10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
IPMI 2.0
Remote Management Controller
Aspeed AST2600
Interfaces
4 x USB 3.2 Gen 1 (2 front, 2 rear) ¦ 1 x VGA - DB-15 ¦ 2 x LAN (10Gigabit Ethernet) - RJ-45 ¦ 1 x LAN (Gigabit Ethernet) - RJ-45
Compliant Standards
FCC SDOC Class A, DOC-A, RoHS
Power Redundancy Scheme
1+1
Voltage Required
AC 100-127/200-240 V
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
OS Provided
No operating system
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
90% (non-condensing)
