Product Form Factor
Rack-mountable - 1U
Built-in Devices
6 x fans
Front Accessible Bays Qty
12
CPU Upgradability
Upgradable
Motherboard Name
S8056GM2NE-2T-TU
Installed Size
6144 GB (max)
Effective Memory Speed
5200 MHz
Rated Memory Speed
5200 MHz
Slots
24 (Total) / 24 (empty)
Interface Type
PCI Express (NVMe)
Graphics Processor
ASPEED AST2600
Ethernet Ports
3 x Gigabit Ethernet
Ethernet Controller
Intel X710-AT2, Realtek RTL8211F
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Protocol
IPMI 2.0
Remote Management Controller
Aspeed AST2600
Slots
2 PCIe 5.0 x16 ¦ 1 PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0
Interfaces
1 x USB 3.2 Gen 1 - Type A ¦ 1 x USB 3.2 Gen 1 ¦ COM ¦ 3 x LAN (10Gigabit Ethernet) - RJ-45 ¦ 1 x USB 3.2 Gen 1 ¦ 2 x USB 3.2 Gen 1
Compliant Standards
FCC SDOC Class A, DOC-A, CB, LVD, VCCI, BSMI, RoHS, C-Tick
Power Redundancy Scheme
1+1
Voltage Required
AC 100-240 V (50/60 Hz)
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
OS Provided
No operating system
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
0 - 90% (non-condensing)
