AI Level
AI PC, AI Workstation
Product Form Factor
Tower
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
CPU
Intel Core Ultra 9 (Series 2) 285
Clock Speed
2.5 GHz (P-core) / 1.9 GHz (E-core)
Max Turbo Speed
5.6 GHz (P-core) / 4.6 GHz (E-core)
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology
Neural Processor Unit (NPU)
Neural Processor Unit (NPU)
Intel AI Boost
NPU Performance Up To (TOPS)
13 TOPS
Total Processor Performance Up To (TOPS)
36 TOPS
AI Datatype Support on NPU
INT8
AI Software Frameworks Supported by NPU
DirectML, OpenVINO, WebNN, WindowsML, ONNX RT
Windows Studio Effects Support
Yes
Installed Size
L3 Cache - 36 MB
Cache Per Processor
36 MB
Installed Size
32 GB (installed) / 128 GB (max)
Technology
DDR5 SDRAM - non-ECC
Effective Memory Speed
5600 MT/s
Rated Memory Speed
5600 MT/s
Slots
4 (Total) / 3 (empty)
Configuration Features
1 x 32 GB
Interface Type
PCI Express 4.0
Features
NVM Express (NVMe)
Controller Interface Type
SATA 6Gb/s / PCIe 4.0 x4 (NVMe)
Multi-GPU Configuration
1 single GPU card / integrated GPU
Graphics Processor
NVIDIA GeForce RTX 5060 Ti / Intel Graphics - up to 8 TOPS
Video Memory
16 GB GDDR7 SDRAM
Video Interfaces
HDMI, DisplayPort
Max Sampling Rate
192 kHz
Compliant Standards
High Definition Audio
Interface (Bus) Type
PCI Express Mini Card (M.2)
Ethernet Controller
Intel I219-LM
Wireless LAN Supported
Yes
Wireless NIC
Intel WI-FI 7 BE200
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7)
Remote Management Protocol
SNMP 2
Features
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support, dual stream (2x2)
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, Wi-Fi CERTIFIED, IEEE 802.3az
Bays
2 (total) / 2 (free) x external 5.25" Slim Line ¦ 2 (total) / 2 (free) x internal 3.5"
Slots
1 (total) / 0 (free) x PCIe 5.0 x16 ¦ 1 (total) / 1 (free) x PCIe 4.0 x16 ¦ 2 (total) / 2 (free) x PCIe 3.0 x1 ¦ 1 (total) / 0 (free) x M.2 Card - 2230 (PCIe 3.0 x1 mode (for wireless module)) ¦ 2 (total) / 1 (free) x M.2 Card - 2280 (PCIe 4.0 x4 mode (for internal storage)) ¦ 2 (total) / 2 (free) x Flex I/O
Interfaces
1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 2 x USB 3.2 Gen 1 (2 rear) ¦ 4 x USB 3.2 Gen 2 (4 in front) ¦ 2 x USB-C 3.2 Gen 2x2 (2 front) (charging) ¦ 1 x audio line-out/line-in (1 rear) ¦ 2 x DisplayPort 2.1 (2 rear) ¦ 3 x USB 2.0 - Type A (3 rear) (two of them with wake functionality) ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 (1 rear) ¦ 1 x HDMI
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop, chassis intrusion sensor
Security Slot Type
Kensington security slot
Compliant Standards
FCC Class B certified, FIPS 140-2 Level 2, RoHS, Common Criteria EAL4+, ERP, VCCI Class B, SEPA, low halogen, UL 62368-1, Japan PC Green Label, Korea Eco-Label, FEMP
Manufacturer Selling Program
HP Smart Buy
Voltage Required
AC 100-240 V (50/60 Hz)
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 11 Pro English
Software
HP Support Assistant, HP Hotkey Support, HP Client Catalogue (free download), HP Setup Integrated OOBE, HP Image Assistant (free download), HP Documentation, HP Connection Optimizer, HP Privacy Settings, HP Cloud Recovery, HP Client Management Script Library (free download), myHP, HSA Fusion for Commercial, HSA Telemetry for Commercial, HP Desktop Support Utilities, HP Smart Support, Poly Lens management software, HP Manageability Integration Kit (free download), HP Connect for Microsoft Endpoint Manager, HP Patch Assistant (free download), HP PC Hardware Diagnostics Windows, HP Services Scan, HP Driver Packs (free download), HP UEFI BIOS Certification level 2.7B
Sustainability Information
EPEAT Compliant
EPEAT Gold
ENERGY STAR Certified
Yes
Dimensions & Weight (Shipping)
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 90% (non-condensing)
