Device Type
VoIP phone adapter
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet
Network / Transport Protocol
TCP/IP, UDP/IP, RTCP, RTP, ARP, PPPoE, IPSec, PPTP, L2TP
Remote Management Protocol
TR-069, HTTP, HTTPS, TFTP, SSH, SNMP 3
Status Indicators
Internet, phone, power
Features
IPv6 support, reset button, wall mountable, DHCP client, Internet Control Message Protocol (ICMP), SNTP support, Cisco Discovery Protocol, LLDP support, NAT support, port forwarding, DiffServ support, Type of Service (ToS), Automated Attendant (IVR), Syslog support, dual image support
Encryption Algorithm
ESP, AES, TLS 1.1, TLS 1.2
Authentication Method
Secure Shell (SSH)
Compliant Standards
IEEE 802.1ab (LLDP), IEEE 802.1p, IEEE 802.1Q
VoIP Protocols
SIP, RTP, RTCP, SRTP
Voice Codecs
G.711a, G.711µ, G.726, G.729a, G.729ab, T.38, G.711
Telephony Interfaces
2 phone (FXS)
IP Telephony Features
Call waiting, call forwarding, call hold, caller ID block/unblock, Caller ID, call transfer, distinctive ringing, Do-not-disturb (DND) support
Interfaces
2 x FXS - RJ-11 ¦ 2 x 100Base-TX - RJ-45
Compliant Standards
Directive 2014/30/EU, Directive 2014/35/EU, UL 60950 Second Edition, CAN/CSA C22.2 No. 60950 Second Edition, IEC 60950-1:2005 Second Edition, AS/NZS 60950-1:2015, AS/NZS CISPR32:2015 Class B, CISPR 32:2015 Class B, EN 55032:2015 Class B, EN 61000-3-2:2014 Class A, EN 61000-3-3:2013, EN 55024:2010+A1:2015, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, FCC Part 15 B, ANSI C63.4-2014, ICES-003:2016
Power Device
External power adapter
Voltage Required
AC 120/230 V / DC 5 V (50/60 Hz)
Power Consumption Operational
5 watt
Service & Support
Limited warranty - 1 year
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
